Setting Automatic Operation Options (SmartStart
The cabinet allows configuration to activate functions automatically when the sash is
opened or closed. The following screens will display sequentially with [OK/Mute].
The first screen provides the option of activating the
blower; if you want the cabinet blower to start every
time you raise the sash, select
[OK/Mute]. If Blower Off
must be manually started from the keypad. When
[OK/Mute] is pressed, the next configuration screen
will appear.
If you want the cabinet lights to turn on every time
the sash is opened, select
[OK/Mute]. If Light Off
be manually illuminated from the keypad. When
[OK/Mute] is pressed, the next configuration screen
will appear if the cabinet is configured for a UV lamp.
If your Cabinet is configured for a UV light, you will
see Fig. 6-13 and 6-14. If you want the UV lamp to
turn on every time the sash is closed, select
UV Light On, and press [OK/Mute]. If
selected, the UV light will not turn on when the sash
is closed. When [OK/Mute]
configuration screen will appear.
Whether the UV Light is initiated from the
Light] button on the keypad, or automatically
initiated upon closing of the sash, this screen
controls the time the UV lamp will remain on.
Select the length of time desired, press
[OK/Mute].
Blower On, and then
is selected, the blower
Light On, and then
is selected, the lights must
UV Light Off
is pressed, the final
[UV
Continuous On
TM
)
OPEN SASH:
START
BLOWER
OPEN SASH:
LIGHT ON
is
CLOSE SASH:
UV LIGHT ON
47
Figure 6-11
Figure 6-12
Figure 6-13
Figure 6-14
