Unit. When you have done this, TAB to the Save box and hit the
ENTER key. The CX9200 will return to the Command window.
Figure 4-8 shows the Infinet Controller window.
Figure 4-8. The Infinet Controller Window
E dit
Command Window - INFINITY1
Infinet Controller - INFINITY1 AHU1
AHU1
Name
920
Model
Floor 1 Air Handling Unit
Description
COMM2
Port
1
Infinet ID
80858
Serial Number
Error
Error Time
0
Error Count
From the Main Menu Bar, you can select View, then Infinet
Controllers to verify your name changes and to view the status of all of
the Infinet controllers.

Configuring COMM3 for the Users Terminal

The default settings are as follows:
• DefaultMode = Autoset
• Baud rate = Baud9600
• TerminalType = VT100
If you need to change any of these settings, or you want to enter a
description, you select Edit Commports and use COMM3 as the name.
