Figure 4-6. The Commport Window
E
COMM1
Name
DefaultMode
(X) Printer
( ) Window
( ) Command
( ) Infinet
( ) Lbus
( ) Autoset
( ) TankNet
( ) Xdriver
Printer
Mode

Configuring COMM2 for Infinet

Select Edit Commports and enter COMM2 at the Name prompt. When
the Commport window comes up, set the DefaultMode attribute to
Infinet.
When you hit the TAB key the Commport window will change slightly
and two more boxes will appear that are labeled Learn and View. These
new selections apply to an Infinet port. The Learn box instructs the
CX9200 to poll the Infinet Network and bring any available controllers
On-line. The View box instructs the CX9200 to print out the status of the
Infinet controllers.
The attributes should be set as follows:
• Description = Infinet Port (for example)
• DefaultMode = Infinet
• Baud rate = Baud19200
Once the attributes are set properly, TAB to the Learn box and hit
ENTER. The CX9200 will respond with a window that says Learn
Mode is Active.
4-10
dit C
Command Window - INFINITY1
Commport - INFINITY1 COMM1
Description FSCS Interface
Baud
( ) Baud300
( ) Baud1200
( ) Baud2400
( ) Baud4800
(X) Baud9600
( ) Baud19200
Configuring the System
onnect L
SAVE
CANCEL
Infinity Smoke Control Guide
