Andover Controls Infinity Manual page 177

Example System Points
Table B-1.
NAME
FL3VAV.Fail
FL3VAV.Opn
FL3VAV.OVR.Cls
FL3VAV.OVR.Opn
FL4RADmp.Cls
FL4RADmp.Fail
FL4RADmp.Opn
FL4RADmp.OVR.Cls
FL4RADmp.OVR.Opn
FL4RADmp.ST.Fail
FL4SADmp.Cls
FL4SADmp.Fail
FL4SADmp.Opn
FL4SADmp.OVR.Cls
FL4SADmp.OVR.Opn
FL4SADmp.ST.Fail
FL4VAV.Cls
FL4VAV.Fail
FL4VAV.Opn
FL4VAV.OVR.Cls
FL4VAV.OVR.Opn
FLR2TCX.Fail
FLR2TCX.OVRR
FLR3TCX.Fail
FLR3TCX.OVRR
FLR4TCX.Fail
FLR4TCX.OVRR
FSCSLinkActive
Horn
LampTest
Main.Key
Andover Controls Corporation
Technical Manuals Online! - http://www.tech-man.com
CX9200
Points
TYPE DESCRIPTION
Numeric Floor3 VAV Damper "FAIL" LED on FSCS
Numeric Floor3 VAV Damper "OPEN" LED on FSCS
Numeric Floor3 VAV Damper "CLOSE" Override Switch on FSCS
Numeric Floor3 VAV Damper "OPEN" Override Switch on FSCS
Numeric Floor4 Return Air Smoke Damper "CLOSED" LED on
FSCS
Numeric Floor4 Return Air Smoke Damper "FAIL" LED on FSCS
Numeric Floor4 Return Air Smoke Damper "OPEN" LED on
FSCS
Numeric Floor4 Return Air Smoke Damper "CLOSE" Override
Switch on FSCS
Numeric Floor4 Return Air Smoke Damper "OPEN" Override
Switch on FSCS
Numeric Floor4 Return Air Smoke Damper Self-Test Fail Flag
Numeric Floor4 Supply Air Smoke Damper "CLOSED" LED on
FSCS
Numeric Floor4 Supply Air Smoke Damper "FAIL" LED on FSCS
Numeric Floor4 Supply Air Smoke Damper "OPEN" LED on
FSCS
Numeric Floor4 Supply Air Smoke Damper "CLOSE" Override
Switch on FSCS
Numeric Floor4 Supply Air Smoke Damper "OPEN" Override
Switch on FSCS
Numeric Floor4 Supply Air Smoke Damper Self-Test Fail Flag
Numeric Floor4 VAV Damper "CLOSED" LED on FSCS
Numeric Floor4 VAV Damper "FAIL" LED on FSCS
Numeric Floor4 VAV Damper "OPEN" LED on FSCS
Numeric Floor4 VAV Damper "CLOSE" Override Switch on FSCS
Numeric Floor4 VAV Damper "OPEN" Override Switch on FSCS
Numeric Floor2 TCX Controller "FAULT" LED on FSCS
Numeric Floor2 TCX Controller "OVERRIDE" LED on FSCS
Numeric Floor3 TCX Controller "FAULT" LED on FSCS
Numeric Floor3 TCX Controller "OVERRIDE" LED on FSCS
Numeric Floor4 TCX Controller "FAULT" LED on FSCS
Numeric Floor4 TCX Controller "OVERRIDE" LED on FSCS
Numeric Flag that tells the "Main" Program that the
"FSCS_Interface" Program is Active
Numeric Audible Annunciator Output on FSCS
Numeric "LAMP TEST" Pushbutton Input on FSCS
Numeric "MASTER KEY" Keyswitch Input on FSCS
TOC
B-5
