Andover Controls Infinity Manual

Smoke control
Hide thumbs
Table of Contents

Advertisement

Quick Links

Controlling Tomorrow's World
Infinity Smoke Control Guide
Electronic Version
Andover Controls Corporation
i
Technical Manuals Online! - http://www.tech-man.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Infinity and is the answer not in the manual?

Questions and answers

Related Manuals for Andover Controls Infinity

Summary of Contents for Andover Controls Infinity

  • Page 1 Controlling Tomorrow’s World Infinity Smoke Control Guide Electronic Version Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 2 This product is subject to change without notice. This document does not constitute any warranty, express or implied. Andover Controls Corporation reserves the right to alter ca- pabilities, performance, and presentation of this product at any time. The following trademarks are used in this manual: CROSSTALK is a registered trademark of Digital Communications Associates, Inc.
  • Page 3 Chapter 1 The Fundamentals of Smoke Control One of the most hazardous situations that you can face in a building is smoke. While fires themselves are often damaging, it is smoke that can cause the most injuries. For example, at the World Trade Towers in February 1993, over 1,000 were injured by the smoke that resulted from the fire.
  • Page 4 The operation of the dedicated smoke control equipment is verified by an automatic self-test that is performed on a weekly basis. Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 5 The difference in pressure (also called the pressure differential) between the smoke-filled area and the surrounding areas acts as a barrier to the smoke, pushing it back into the smoke-filled area. The next illustration shows how this works. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 6 The amount of air required to keep the smoke from penetrating the open space is quite large, so you should avoid this sort of situation when possible. Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 7 The Fundementals of Smoke Control Figure 1-3. Keeping Smoke Away from a Large Opening Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 8 For instance, if the building has a sprinkler system, then the smoke control system does not need to control a large quantity of smoke, since the size of any fire should be smaller. Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 9 National Fire Protection Association in their publication NFPA 92A, Smoke Control Systems, 1988 edition. You can find additional information regarding fire alarm control units in the Underwriters Laboratories Inc. Standard UL 864. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 10 Consider the number of zones surrounding the fire zone that should be pressurized. While in theory, all you need to do is to pressurize all of the Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 11 Later, you have to program this information into the smoke control system. This information gives the smoke control system a strategy for containing smoke in each possible fire zone. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 12 °R to °F is: °R = °F + 460. is the absolute temperature of the hot gases in the fire zone. It is also measured in °R. Typically, T is 2160° R (1700° F). 1-10 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 13 Since larger openings, like doorways that are normally open, require large amounts of air to maintain pressurization, you should avoid this type of situation. Andover Controls Corporation 1-11 Technical Manuals Online! - http://www.tech-man.com...
  • Page 14 Fire dampers are dampers that block a fire from penetrating a fire rated partition via a duct. These dampers are normally open, held in place by a fusible link. The fusible link is a heat-sensitive device that releases the 1-12 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 15 HVAC system, since maintaining comfort levels is not an issue. It simply has to make sure the air sent into an area is not going to damage the building’s interior. Andover Controls Corporation 1-13 Technical Manuals Online! - http://www.tech-man.com...
  • Page 16 The control system has to decide whether or not to shut down the air inlet. You should refer to NFPA 90A for more information on smoke detectors in inlets and outlets. 1-14 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 17 Figure 1-4. The Effects of Too Much and Too Little Pressure Too Little Pressure Too Much Pressure Stairtower Building Stairtower Building Andover Controls Corporation 1-15 Technical Manuals Online! - http://www.tech-man.com...
  • Page 18 The Fundementals of Smoke Control Figure 1-5. Parts of a Stairtower System Exhaust Fan or Vent Supply Duct Pressure Vents Supply Fan Fire Rated Door Building Stairtower 1-16 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 19 Therefore, when calculating the force required to open the door, you may need to lower the door closer force. Andover Controls Corporation 1-17 Technical Manuals Online! - http://www.tech-man.com...
  • Page 20 (assuming there is more than one). More sophisticated systems use ducts to deliver air to several points in the stairtower. The dampers can be controlled to maintain the appropriate pressure in their zone. 1-18 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 21 See the next diagram for an example of a bypass duct system. Figure 1-8. A Bypass Pressure Control System Bypass Duct Dampers Air Intake Bypass Duct Andover Controls Corporation 1-19 Technical Manuals Online! - http://www.tech-man.com...
  • Page 22 Such a fan should be designed to operate only when the stairtower is overpressurized. It should never be on when the pressure differential between the building and the stairtower is below the lowest limit. 1-20 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 23 And since most shafts are not designed to be inspected after the elevators are installed, finding and repairing cracks that would let smoke infiltrate or pressure escape is difficult. Andover Controls Corporation 1-21 Technical Manuals Online! - http://www.tech-man.com...
  • Page 24 In general, elevators should not be used as an escape route during an evacuation. 1-22 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 25 This panel, called a Firefighter’s Smoke Control Station (FSCS), allows firefighting personnel to take manual control of the smoke control system. Andover Controls Corporation 1-23 Technical Manuals Online! - http://www.tech-man.com...
  • Page 26 Also, if such a switch is thrown, a trouble alarm must sound in the building’s main control center. 1-24 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 27 75 seconds for a damper. If, within that time, the proof sensors do not report that the piece of equipment has responded to the control system’s command, the FSCS indicates that the piece of equipment has failed. Andover Controls Corporation 1-25 Technical Manuals Online! - http://www.tech-man.com...
  • Page 28 Dampers for Use in Smoke Control Systems. Underwriters Laboratories, Inc. Underwriters Laboratories, Inc. UL 555, Fire Dampers. Underwriters Laboratories, Inc. Underwriters Laboratories, Inc. UL 864, Control Units for Fire- Protective Signaling Systems. Underwriters Laboratories, Inc. 1-26 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 29 Chapter 2 Infinity Smoke Control System Components This chapter presents a general overview of the Infinity smoke control system and describes the UL listed system components used, the features of each component, and their role within the system. The following components are described: •...
  • Page 30 Infinity Smoke Control System Components Smoke Control System Overview Figure 2-1 shows the components that are used in an Infinity smoke control system and how they are connected together. The component descriptions in the remainder of this chapter describe in more detail the role of each component in the system.
  • Page 31 Infinity Smoke Control System Components CX9200 Controller The CX9200 serves as the central controller in the Infinity smoke control system. It controls the communication between the other system components within the smoke control system. The CX9200 can be used in a dedicated or a non-dedicated smoke control application. The CX9200 connects to other controllers in the following ways: •...
  • Page 32 Infinity Smoke Control System Components SCX920S Controller The SCX920S controller is used to control a large piece of equipment, such an AHU (Air Handling Unit), or several smaller pieces of equipment, such as smoke dampers. The SCX920S communicates with the CX9200, as well as other Infinet controllers, via the Infinet network.
  • Page 33 Infinity Smoke Control System Components TCX840 Series Controllers The TCX840 series includes the TCX840, TCX843, TCX845, TCX846 controllers. The TCX840 series controllers are used to control small pieces of equipment that require fewer I/O points than an SCX920S, such as VAV boxes or stairwell fans. The TCX840 series communicates with the CX9200, as well as other Infinet controllers, via the Infinet network.
  • Page 34 Infinity Smoke Control System Components TCX850 Series Controllers The TCX850 series includes the TCX850, TCX851, TCX852, TCX853, and TCX855 controllers. The TCX850 series controllers are used to control small pieces of equipment that require fewer I/O points than an SCX920S, such as VAV boxes or stairwell fans. The TCX850 series communicates with the CX9200, as well as other Infinet controllers, via the Infinet network.
  • Page 35 Infinity Smoke Control System Components TCX860 Series Controllers The TCX860 series includes the TCX860, TCX861, TCX862, and TCX863 controllers. Like the TCX850 series, the TCX860 series controllers are used to control VAV boxes. The TCX860 series communicates with the CX9200, as well as other Infinet controllers, via the Infinet network.
  • Page 36 Infinity Smoke Control System Components TCX865 Series Controllers The TCX865 series includes the TCX865, TCX866, TCX867, TCX868 and TCX869 controllers. Like the TCX860 series, the TCX865 series controllers are used to control VAV boxes. The TCX865 series communicates with the CX9200, as well as other Infinet controllers, via the Infinet network.
  • Page 37 Infinity Smoke Control System Components EnergyLink 2500 The EnergyLink 2500 is an active network hub for the EnergyNet network that has slots for plugging in various media interface modules. The EnergyLink 2500 can perform the following functions: • Allows the Energynet to be used in a star configuration •...
  • Page 38 Infinity Smoke Control System Components Infilink 200 The InfiLink 200 is a repeater and network expander for the Infinet network. The InfiLink 200 can perform the following functions: • Amplify an RS-485 Infinet signal, thus allowing for extension beyond 4,000 feet •...
  • Page 39 Infinity Smoke Control System Components Infilink 210 The InfiLink 210 is a fiber optic repeater for the Infinet network. The InfiLink 210 is used to convert a single RS-485 Infinet signal into 2 fiber optic Infinet channels. Therefore, if an Infilink 210 is used at each Infinet controller, the entire network can use fiber optics.
  • Page 40 Infinity Smoke Control System Components The FSCS The Firefighter’s Smoke Control Station (FSCS) is a custom panel that provides full monitoring and manual control capability over all smoke control equipment. In the event of an emergency, it is used by the fire department to override the smoke control system.
  • Page 41 Infinity Smoke Control System Components Status Indicators The actual status of the smoke control equipment must be clearly indicated on the FSCS by the use of visual indicators with appropriate legends. Fans must have a single indicator that turns on when the fan’s differential pressure “proof sensor”...
  • Page 42 Turning the Master key ON is the only way to silence the alarm. Ordering Information Andover Controls’ UL listing includes a custom FSCS panel that is manufactured by Automation Displays Incorporated. For ordering information, contact: Automation Displays Inc.
  • Page 43 Infinity Smoke Control System Components Design Guidelines In order to have the FSCS built to your specifications, you will need to supply the following: • An accurate drawing of the smoke control system. This drawing will be used to create the FSCS front panel graphic.
  • Page 44 The Fire Panel connects to all of the smoke detectors, fire detectors, manual pull boxes, fire alarms, etc.within the building. When one of the Fire Panel sensors detects a problem, the Fire Panel informs the Infinity smoke control which sensor is in an alarm condition and what the alarm condition is.
  • Page 45 Installation and Layout This chapter gives instructions for installing and interconnecting the Infinity smoke control system components. All wiring in an Infinity smoke control system must comply with the National Electric Code (NFPA 70), as well as any state or local regulations.
  • Page 46 Installation and Layout Installing the CX9200 For detailed information on how to mount and connect the wiring to the CX9200 and it’s peripherals, refer to the following Andover Controls documentation: Infinity CX9200 Hardware Installation Guide (P/N 30-3001-347) Energylink 2500 Installation Guide (P/N 30-3001-393)
  • Page 47 Installation and Layout Figure 3-1. Isolating the CX9200 CX9200 with CX9200 Energylink 2500 Fiber Energynet Optics Energynet Smoke Control Components Other Energynet Components Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 48 FSCS that turns on when the outputs are overridden. The FSCS audible indicator must also turn on. • If the AC input voltage is to be set to 24 V, an Andover Controls’ Listed transformer must be used to supply the 24V AC input power .
  • Page 49 Installation and Layout The TCX840 and TCX850 series • Only an Andover Controls’ Listed transformer may be used to supply the 24V AC input power for the TCX840 and TCX850 series. These transformers must be placed in a Listed enclosure and must be wired according to the National Electric Code, as well as any state or local regulations.
  • Page 50 Figure 3-2 shows the use of the Infilink 210 to isolate the Infinet smoke control components. Figure 3-2. Isolating the Infinet Controllers SCX920S TCX840 series TCX850 series CX9200 TCX860/865 series Infilink 200 Infilink Infilink Fiber Optics Infinet Smoke Control Components Other Infinet Controllers Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 51 Inside the FSCS Figure 3-3 shows what the typical components inside an FSCS will look like. Since the FSCS is custom made for each application, the internal layout will vary from panel to panel. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 52 WIRING TROUGH 1 2 3 4 RS-232 PROTECTION Q-CARD PROCESSOR PCB IN COM RS-232 FIELD WIRING TERMINALS AC POWER FIELD WIRING TERMINALS +5V DC POWER SUPPLY POWER SWITCH AND LINE FUSE Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 53 FIELD WIRING TERMINALS. This cable must be less than 20 feet in length, and must be enclosed in conduit. Figure 3-5 shows this terminal block and how it is wired to the CX9200. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 54 As stated in the previous chapter, if you are not using a Fire Panel that is part of the Andover Controls Listing, you will have to connect the Fire Panel to the smoke control system using the Zoned Wiring method. This involves connecting a set of wires for each zone from the Fire Panel to the FSCS.
  • Page 55 1200 Baud 600 Baud 300 Baud Andover Controls recommends setting the FSCS for 9600 baud, with auto-blanking disabled, therefore all the dipswitches are OFF. Figure 3-6 shows the location of the switches on the Q-Card. Figure 3-6. The Q-Card switch settings...
  • Page 56 CX9200 DB-25 XMIT Pin 2 (TD) Pin 3 (RD) Pin 7 (GND) b. Edwards Systems Technology Model IRC-3 CX9200 DB-25 Pin 2 (TD) Pin 3 (RD) Pin 7 (GND) COMM 3-12 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 57 For more detailed information concerning these and other topics, refer to the following Andover Controls manual: Infinity CX Programmer’s Guide (P/N 30-3001-166) This chapter does not attempt to explain the system’s programming language or how to write smoke control application programs.
  • Page 58 WINDOW on your terminal as you are typing. The CX9200 will respond with the Infinity Window. The Infinity Window prompts you for a User Name first. If the CX9200 has just been powered up or reset, you must type in the predefined User Name ACC.
  • Page 59 Using the Command Window Once you have logged on to the CX9200, the Command window will be displayed. The Command window is the main window in the Infinity system. Along with the Command window, you will see the Main Menu Bar at the top of the screen and the StatusBar at the bottom.
  • Page 60 The CX9200 will respond by printing the Date and Time inside the Command window. The StatusBar The StatusBar can be used by a program to Print any information that is available in the Infinity system. Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 61 Configuring the System Using the Menus Although many of the Infinity Menus look different, they all respond to the same set of keystrokes. This section summarizes some of these keystrokes. You change between the Main Menu Bar selections using the LEFT and RIGHT ARROW keys.
  • Page 62 Configuring the System Assigning Security Levels to Users This section describes how to assign new Users for the Infinity system and how to set the Passwords and Security Levels for these Users. Starting at the Main Menu Bar, select the Edit function. A pulldown menu will appear showing what Edit functions are available.
  • Page 63 Security Level CANCEL ( ) No Access ( ) View Only ( ) Acknowledge Alarms ( ) Change Values DELETE ( ) Enable/Disable ( ) Configure ( ) Program TEACH (X) Administrate Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 64 Figure 4-5 shows the System Time window. Figure 4-5. The System Time Window onnect ogout Command Window - INFINITY1 R> System Time - INFINITY1 Date and Time March 24 1994 15:20:00 CANCEL Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 65 • Baud rate = Baud9600 Once the information has been entered, TAB to the SAVE box and hit the ENTER key. Comm1 has now been configured. Figure 4-6 shows the Commport window. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 66 • Baud rate = Baud19200 Once the attributes are set properly, TAB to the Learn box and hit ENTER. The CX9200 will respond with a window that says Learn Mode is Active. 4-10 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 67 The CX9200 will display the Infinet Controller window. You can now change the name of the Infinet controller. You can also add a Description for this Infinet controller, such as Floor 1 Air Handling Andover Controls Corporation 4-11 Technical Manuals Online! - http://www.tech-man.com...
  • Page 68 • TerminalType = VT100 If you need to change any of these settings, or you want to enter a description, you select Edit Commports and use COMM3 as the name. 4-12 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 69 Type print COMM4 xdriverstatus at the R> prompt and the CX9200 should respond with “Installed”. See the section titled Creating and Editing Points for instructions on how to create variables that use the Xdriver port. Andover Controls Corporation 4-13 Technical Manuals Online! - http://www.tech-man.com...
  • Page 70 This section explains how to create and edit a Point. A point refers to a variable that is used by the Infinity system. For example, a Point can be an input on a controller, an output on a controller, a numeric variable, a character string, or an Xdriver variable.
  • Page 71 DETAILS Creating a Numeric Point A Numeric Point is a variable that can be used by the Infinity system. A Numeric Point is created the same way as an Input or Output point. When you call up the Point window, set the Type to Numeric. A Numeric Point does not have selections for Channel Number or Electrical Type because they do not apply.
  • Page 72 Figure 4-10 shows the Simplex Xdriver fields. Figure 4-10. Simplex Xdriver Fields onnect ogout Point - INFINITY1 Smoke.SPX COMM4 Port SAVE Card CANCEL Point Sub-Point Status/Time Figure 4-11 shows the Edwards Systems Technology fields. 4-16 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 73 Port SAVE Loop CANCEL Address Refer to Appendix A for a list of the possible Xdriver values that can be received from the Fire Panel, and what Events they correspond to. Andover Controls Corporation 4-17 Technical Manuals Online! - http://www.tech-man.com...
  • Page 74 CX9200 and in the Infinet controllers, determine how the Infinity smoke control system operates. The Programs are written in Andover Controls’ Plain-English language. It is beyond the scope of this manual to explain the Plain-English language or how to write Programs. Refer to the following Andover...
  • Page 75 If not, you can Start or Stop the Program from the Command window, or from another Program. To exit the Editor and return to the Command window, select File Quit from the File Menu Bar. Andover Controls Corporation 4-19 Technical Manuals Online! - http://www.tech-man.com...
  • Page 76 Summary, or the Message window. It will also allow you to Edit a Point, Edit a System Variable, or create a split screen that contains the Command Window on the top of the screen and the Editor on the bottom half. 4-20 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 77 Smoke Control Programs Chapter 5 Smoke Control Programs This chapter describes some example Infinity smoke control programs. These example programs are for illustrative purposes only. Since each system is unique, your programs will not be identical to these examples, but the same principles will apply.
  • Page 78 Floor 3 SCX920S Smoke TCX840 Dampers VAV Terminal Floors 2-4 Floor 2 SCX920S AHU-1 Floor 1 INFINET RS-485 RS-232 RS-232 Firefighter’s Smoke CX9200 Fire Panel Control Station Main Controller Simplex or EST Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 79 CLOSED ZONE 1 AUTO CLOSED AUTO CLOSED OPEN OPEN SMOKE ALARM PRESS AUTO EXHAUST AHU-1 EX DAMPER AHU-1 RETURN FAN OPEN FAIL CLOSED STATUS FAIL OPEN AUTO CLOSED AUTO ANDOVER CONTROLS Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 80 Determines whether or not, and in which zones, to perform smoke control. Sets the FSCS Alarm LEDs based on the inputs from the Fire Panel. SmokeSelfTest Program Runs a weekly self-test on the dedicated controllers. Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 81 Refer to Appendix B for an explanation of the Points used in the example programs. Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 82 FL2SADmp.Cls = SMKDMPRS Fl2.SASDmp.Cls FL2RADmp.Opn = SMKDMPRS Fl2.RASDmp.Opn FL2RADmp.Cls = SMKDMPRS Fl2.RASDmp.Cls FL3SADmp.Opn = SMKDMPRS Fl3.SASDmp.Opn FL3SADmp.Cls = SMKDMPRS Fl3.SASDmp.Cls FL3RADmp.Opn = SMKDMPRS Fl3.RASDmp.Opn FL3RADmp.Cls = SMKDMPRS Fl3.RASDmp.Cls FL4SADmp.Opn = SMKDMPRS Fl4.SASDmp.Opn Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 83 This function sets the CX9200 numerics in the left column equal to the Infinet controller points in the right column. The CX9200 numerics are used to control their corresponding LED on the FSCS and to set the “.OVRR” override fault numerics. Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 84 “ “AH2Rfan.Fail “ “FL4RADmp.Opn “ “FL4RADmp.Fail “ “FL4RADmp.Cls “ “Zone4.ALM “ “STRWL.ALM “ “AHU2.Fail “ “AHU2.OVRR “ “FLR4TCX.Fail “ “FLR4TCX.OVRR “ “AHU1.Fail “ “AHU1.OVRR “ “FLR3TCX.Fail “ “FLR3TCX.OVRR “ “SMKDMPRS.Fail “ Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 85 “ “AH1OADmp.Cls “ “AH1RADmp.Opn “ “AH1RADmp.Fail “ “AH1RADmp.Cls “ “AH1EADmp.Opn “ “AH1EADmp.Fail “ “AH1EADmp.Cls “ “AH1Rfan.On “ “AH1Rfan.Fail “ “Zone1.ALM “ “SpareLamp “ “SpareLamp “ “SpareLamp “ “SpareLamp “ “Horn “ Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 86 LED 3 --> AH2Sfan.ON (AHU2 Supply Fan STATUS LED) LED 80 --> Horn (Audible Annunciator) The last output, called “Horn”, controls the state of the audible annunciator on the FSCS. 5-10 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 87 Wherever there is an “X” in the string the LED will be ON, and wherever there is a “Z” the LED will be OFF. Refer to Appendix C for a complete discussion of the FSCS communications protocol. 5-11 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 88 SwitchState = On Else SwitchState = Off AH2OADmp.OVR.Cls = SwitchState If mid(InBuffer, SWS + 7, 1) = “A” and Main.Key then ~ SwitchState = On Else SwitchState = Off AH2RADmp.OVR.Opn = SwitchState 5-12 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 89 If mid(InBuffer, SWS + 18, 1) = “A” and Main.Key then ~ SwitchState = On Else SwitchState = Off FL4RADmp.OVR.Cls = SwitchState If mid(InBuffer, SWS + 19, 1) = “A” and Main.Key then ~ SwitchState = On Else SwitchState = Off 5-13 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 90 SwitchState = On Else SwitchState = Off FL3VAV.OVR.Cls = SwitchState If mid(InBuffer, SWS + 30, 1) = “A” and Main.Key then ~ SwitchState = On Else SwitchState = Off Zone3.PRS = SwitchState 5-14 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 91 If mid(InBuffer, SWS + 41, 1) = “A” and Main.Key then ~ SwitchState = On Else SwitchState = Off AH1Sfan.OVR.Off = SwitchState If mid(InBuffer, SWS + 42, 1) = “A” and Main.Key then ~ SwitchState = On Else SwitchState = Off 5-15 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 92 If mid(InBuffer, SWS + 52, 1) = “A” then SwitchState = On Else ~ SwitchState = Off Zone1.CON = SwitchState If mid(InBuffer, SWS + 53, 1) = “A” then SwitchState = On Else ~ SwitchState = Off Zone2.CON = SwitchState 5-16 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 93 Switch 0 --> SpareLamp (not used) Switch 1 --> AH3Sfan.OVR.On (AHU3 Sfan Overridden ON) Switch 2 --> AH3Sfan.OVR.Off (AHU3 Sfan Overridden OFF) Switch 3 --> AH2Sfan.OVR.On (AHU2 Sfan Overridden On) 5-17 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 94 Fire Panel (if used), and the MAIN.KEY input MUST be updated even if the Master Key is turned OFF. Refer to Appendix C for a complete discussion of the FSCS communications protocol. 5-18 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 95 If COMM1 TimedOut then Goto Found_Problem If Result = Success then Goto Decode_Data Else Goto Found_Problem Decode_Data: DecodeSwitches() Goto Output_Lamp Output_Lamp: Print OutputLampString(); to COMM1 Goto Wait_For_Output Wait_For_Output: If COMM1 PrintDone then Status2 = Off 5-19 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 96 5 seconds (Timeout+1), then the program will turn ON the Status2 indicator on the CX9200 and Close the Comm port. The Status2 indicator signals an FSCS communications fault. 5-20 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 97 Result = read(COMM1, 100, InBuffer, 500, “)”) This command tells the CX9200 to wait for 100 characters, OR 5 seconds, OR until it receives the right parenthesis. Under normal circumstances, it will receive the parenthesis first. 5-21 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 98 TRUE, therefore the corresponding .Fail numeric is set TRUE. In the MAIN Program, MaxCtlrTime is set to 10 seconds to allow Infinet to Reconfigure without the FSCS turning on a Fault alarm. 5-22 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 99 If not (((AHU1 EADmp = On) and (AHU1 EADmp.Opn <> On)) or ((AHU1 EADmp = -On) and (AHU1 EADmp.Cls <> On))) then PlantTimer[7] = Time AH1EADmp.Fail = (Time - PlantTimer[7]) > MaxDamperTime 5-23 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 100 FL2RADmp.Fail = (Time - PlantTimer[13]) > MaxDamperTime ‘ Plant 14 If not (((SMKDMPRS Fl3.SASDmp = On) & (SMKDMPRS Fl3.SASDmp.Cls <> On)) or ((SMKDMPRS Fl3.SASDmp = Off) & (SMKDMPRS Fl3.SASDmp.Opn ~ <> On))) then PlantTimer[14] = Time 5-24 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 101 FL4VAV.Fail = (Time - PlantTimer[20]) > MaxDamperTime ‘ Turn ON FSCS Fail LEDs for a Weekly Self Test Failure of a Dedicated Controller If AH3Sfan.ST.Fail then AH3Sfan.Fail = On If FL2SADmp.ST.Fail then FL2SADmp.Fail = On 5-25 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 102 ON if the self-test fail numeric (.ST.Fail) for that piece of equipment is ON. Since this is a function, only the final value of the numeric will be used by the CX9200. 5-26 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 103 If CloseList(CurrentPoint) <> Success then Print “ ** Can Not Close Numeric List. ** “ Endif SetHorn: Status1 = TempHorn If Main.Key = Off then Horn = TempHorn Else Horn = Off Stop 5-27 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 104 When the Master Key is turned ON, the audible annunciator will be turned OFF. The Status1 indicator on the CX9200 will turn ON if there are any Faults, Overrides, or Alarms. The Master Key will not turn OFF the Status1 indicator. 5-28 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 105 ReadPoints: While GetObject(CurrentPoint) = Success Print CurrentPoint Name to NameStg If search(NameStg, “.Fail”) or search(NameStg, “.OVRR”) then Set CurrentPoint Value = Off Endif Endwhile ClosePointsList: If CloseList(CurrentPoint) <> Success then 5-29 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 106 FSCS is pressed. The CLEAR FAULTS pushbutton will only be acknowledged if the Master Key is ON, therefore the faults can only be cleared when the Master Key in ON. 5-30 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 107 If FIRST.SMK then Return ‘ Initiate Only One Smoke Control Strategy If Zone1.ALM then Zone1.SMK = On Else If Zone2.ALM then Zone2.SMK = On Else If Zone3.ALM then Zone3.SMK = On Else 5-31 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 108 • Clear the Smoke Control numeric (“.SMK”), if the Alarm (“.ALM”) goes away. Therefore there is no need to reset the Infinity smoke control system. When the Alarm is cleared at the Fire Panel, it also resets the smoke control system.
  • Page 109 If FL4RADmp.Fail then FL4RADmp.ST.Fail = On OpenDampersS: SMKDMPRS DefaultDmprPosn = Off WaitForDampersSO: ‘ Wait for max damper plant time + 5 Secs to detect fault. If TS < (MaxDamperTime + 5) then Goto WaitForDampersSO 5-33 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 110 If FL3SADmp.ST.Fail then Status4 = On If FL3RADmp.ST.Fail then Status4 = On If FL4SADmp.ST.Fail then Status4 = On If FL4RADmp.ST.Fail then Status4 = On TestComplete: Print “ Weekly Self Test Complete “, Time 5-34 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 111 • Print “Weekly Self Test Complete” and the Time to the Message window. • Set the numeric SelfTested to TRUE, therefore the system will not perform another self-test until the following week. 5-35 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 112 ‘Run ClearFaults if Fault.Clear Button is Pushed If Fault.Clear and ClearFaults Status is not Active then Run ~ ClearFaults ‘ Check if time for Weekly self test. Run Self-Test if There are no 5-36 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 113 • If the FSCS_Interface program is not running (FSCSLinkActive is FALSE), Then set FSCSLinkActive to TRUE and Run the FSCS_Interface program. • Run the HornControl program if it is not already running. 5-37 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 114 • Print the Time to the COMM3 Statusbar if the SmokeSelfTest program is not running. • Delay for 1 second, then Goto MainLoop: and repeat the sequence again. 5-38 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 115 If Main Status is not Active then Goto Restart Goto WaitForErrors WaitForErrors: If TS > 2 then Goto CheckForErrors Restart: Enable HornControl Enable FSCS_Interface Enable ClearFaults Enable SmokeSelfTest Enable Main Run Main Errors = 0 Goto Initialize 5-39 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 116 In order to restart the system, this program Enables all of the programs in the CX9200, Runs the Main program, then sets ERRORS = 0. 5-40 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 117 This function turns ON the numeric OverrideON if any of the outputs are overridden. The OverrideOn flag is used by the CX9200 to turn on an Override Fault on the FSCS. 5-41 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 118 Fl2.SASDmp = On Else If INFINITY1 Zone1.SMK or INFINITY1 Zone3.SMK ~ or INFINITY1 Zone4.SMK or INFINITY1 ~ STRWL.SMK then Fl2.SASDmp = Off Else Fl2.SASDmp = DefaultDmprPosn Endif Endif Endif Endif Endif Endif 5-42 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 119 If INFINITY1 FL3SADmp.OVR.Opn then Fl3.SASDmp = Off Else If INFINITY1 Zone3.EXH then Fl3.SASDmp = On Else If INFINITY1 Zone3.PRS then Fl3.SASDmp = Off Else If INFINITY1 Zone3.SMK then Fl3.SASDmp = On 5-43 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 120 INFINITY1 Zone4.SMK or INFINITY1 ~ STRWL.SMK then Fl3.RASDmp = On Else Fl3.RASDmp = DefaultDmprPosn Endif Endif Endif Endif Endif Endif ‘ Floor (Zone) 4 Smoke Damper Control ‘ Supply Air Damper 5-44 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 121 Else If INFINITY1 Zone4.PRS then Fl4.RASDmp = On Else If INFINITY1 Zone4.SMK then Fl4.RASDmp = Off Else If INFINITY1 Zone1.SMK or INFINITY1 Zone2.SMK ~ or INFINITY1 Zone3.SMK or INFINITY1 ~ 5-45 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 122 Fl2.SASDmp = On Else If INFINITY1 FL2SADmp.OVR.Opn then Fl2.SASDmp = Off Else If INFINITY1 Zone2.EXH then Fl2.SASDmp = On Else If INFINITY1 Zone2.PRS then Fl2.SASDmp = Off Else If INFINITY1 Zone2.SMK then 5-46 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 123 • If none of the above events have occurred, then set the state of the damper is set equal to the numeric DefaultDmprPosn. In this case, the SmokeSelfTest program in the CX9200 sets the value of DefaultDmprPosn in order to perform a weekly self-test. 5-47 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 124 Smoke Control Programs The other five dampers are controlled the same way, except they are controlled by different numerics. 5-48 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 125 This function turns ON the numeric OverrideON if any of the outputs are overridden. The OverrideOn flag is used by the CX9200 to turn on an Override Fault on the FSCS. 5-49 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 126 Sfan = Default.Sfan ‘ Normal HVAC Control Endif Endif Endif Endif Endif Endif ‘ Return Fan Control If INFINITY1 AH1Rfan.OVR.On then Rfan = On Else If INFINITY1 AH1Rfan.OVR.Off then Rfan = Off Else 5-50 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 127 OADmp = -On ‘ Exhaust Else If INFINITY1 Zone2.SMK or INFINITY1 Zone3.SMK ~ or INFINITY1 Zone4.SMK or INFINITY1 ~ STRWL.SMK then OADmp = On ‘ pressurize Else OADmp = DefaultDmpr.OA ‘ Normal HVAC Control 5-51 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 128 Endif ‘ Return’ Air Damper If INFINITY1 AH1RADmp.OVR.Opn then RADmp = On Else If INFINITY1 AH1RADmp.OVR.Cls then RADmp = -On Else If INFINITY1 Zone1.EXH then RADmp = -On ‘Close Else 5-52 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 129 • HVAC control The HVAC control is performed by setting the default values for each fan or damper: Default.Sfan, Default.Rfan, DefaultDmpr.OA, DefaultDmpr.EA, DefaultDmpr.RA. This program also calls the OVR_Check function. 5-53 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 130 This program is for demonstration purposes only and is used to show how the smoke control modes have a higher priority than the HVAC modes. This program does not perform an HVAC function. 5-54 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 131 This function turns ON the numeric OverrideON if any of the outputs are overridden. The OverrideOn flag is used by the CX9200 to turn on an Override Fault on the FSCS. 5-55 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 132 Else Sfan = Default.Sfan ‘ Normal HVAC Control Endif Endif Endif Endif Endif Endif ‘ Return Fan Control If INFINITY1 AH2Rfan.OVR.On then Rfan = On Else If INFINITY1 AH2Rfan.OVR.Off then 5-56 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 133 INFINITY1 Zone4.EXH then OADmp = -On ‘All zones in exhaust Else If INFINITY1 Zone2.SMK and INFINITY1 Zone3.SMK ~ and INFINITY1 Zone4.SMK then OADmp = -On ‘ Close Damper all zones in smoke 5-57 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 134 If INFINITY1 Zone1.SMK or INFINITY1 STRWL.SMK ~ then EADmp = -On ‘ pressurize smoke in Zone 1 or Stairs Else EADmp = DefaultDmpr.EA ‘ Normal HVAC Control Endif Endif Endif Endif Endif Endif 5-58 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 135 Air damper, Exhaust Air damper, and Return Air damper for AHU2. Each fan or damper is controlled by it’s own set of nested “if-then-else” statements. The nested “if-then-else” statements prioritize the control modes as follows: 5-59 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 136 • HVAC control The HVAC control is performed by setting the default values for each fan or damper: Default.Sfan, Default.Rfan, DefaultDmpr.OA, DefaultDmpr.EA, DefaultDmpr.RA. This program also calls the OVR_Check function. 5-60 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 137 This program is for demonstration purposes only and is used to show how the smoke control modes have a higher priority than the HVAC modes. This program does not perform an HVAC function. 5-61 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 138 Sfan = Off ‘Stop Supply Fan as Zone in Fire Else If INFINITY1 Zone1.SMK or INFINITY1 Zone2.SMK or ~ INFINITY1 Zone3.SMK or INFINITY1 Zone4.SMK then Sfan = On ‘pressurize Else 5-62 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 139 • The FSCS overrides: ON-OFF • Automatic Smoke Control • Weekly Self-Test The SmokeSelfTest program in the CX9200 performs the weekly self- test by setting the value of DefaultFanPosn. 5-63 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 140 VAVDmp = -On ‘ Exhaust Zone Close VAV Else If INFINITY1 Zone1.SMK or INFINITY1 Zone3.SMK ~ or INFINITY1 Zone4.SMK or INFINITY1 ~ STRWL.SMK then VAVDmp = On ‘ pressurize Zone 5-64 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 141 The nested “if-then-else” statements prioritize the control modes as follows: • The FSCS overrides: OPEN-CLOSE • Automatic Smoke Control • HVAC control The HVAC control is performed by setting the value of DefaultDmprPosn. 5-65 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 142 This program is for demonstration purposes only and is used to show how the smoke control modes have a higher priority than the HVAC modes. This program does not perform an HVAC function. 5-66 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 143 If INFINITY1 Zone1.SMK or INFINITY1 Zone2.SMK ~ or INFINITY1 Zone4.SMK or INFINITY1 ~ STRWL.SMK then VAVDmp = On ‘ pressurize Zone Else VAVDmp = DefaultDmprPosn ‘ Normal HVAC Control Endif 5-67 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 144 The nested “if-then-else” statements prioritize the control modes as follows: • The FSCS overrides: OPEN-CLOSE • Automatic Smoke Control • HVAC control The HVAC control is performed by setting the value of DefaultDmprPosn. 5-68 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 145 This program is for demonstration purposes only and is used to show how the smoke control modes have a higher priority than the HVAC modes. This program does not perform an HVAC function. 5-69 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 146 Damper = 0 ‘Open VAV Else If INFINITY1 Zone4.SMK then Damper = 1 ‘ Exhaust Zone Close VAV Else If INFINITY1 Zone1.SMK or INFINITY1 Zone2.SMK ~ or INFINITY1 Zone3.SMK or INFINITY1 ~ 5-70 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 147 The HVAC control is performed by setting the value of DefaultDmprPosn. In this example, setting the output to 0 will open the damper, and setting the damper to 1 will close the damper. 5-71 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 148 This program is for demonstration purposes only and is used to show how the smoke control modes have a higher priority than the HVAC modes. This program does not perform an HVAC function. 5-72 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 149 FSCS OPEN and CLOSE LEDs. The DamperPosition numeric is used by the CX9200 PlantFaultCheck function to determine if the damper reaches it’s desired state within 75 seconds, per NFPA 92A. 5-73 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 150 This program causes the TCX861 to perform a Learn of the damper position whenever the controller is power-up or reset. The program is triggered by the Powerfail system variable on the TCX861. 5-74 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 151 Chapter 6 System Operation This chapter provides operating instructions for an Infinity smoke control system. Since the equipment used in each system will be configured and programmed differently, and the FSCS will be custom- made for each system, these instructions will be somewhat generic.
  • Page 152 Figure 6-1 shows an example of the FSCS controls for a fan. Figure 6-1. Fan Controls Equipment Name AHU-1 SUPPLY FAN Green STATUS LED Amber FAIL LED STATUS FAIL AUTO Override Switch Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 153 (AUTO) and either force the damper OPEN or CLOSED. This switch is functional only after the Master Key has been turned ON. This switch has the highest control priority in the system. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 154 Controller Name AHU-1 CONTROLLER Areas Served FLOOR 1 Amber OVERRIDE LED Amber FAULT LED FAULT OVERRIDE • The amber FAULT LED indicates that the CX9200 has lost communications with the Infinet controller. Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 155 The FSCS Operating Instructions Sheet on the following page is a summary of the indicators and controls on the FSCS. It should be removed from this manual, framed, and mounted adjacent to the FSCS. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 156 Technical Manuals Online! - http://www.tech-man.com...
  • Page 157 FIREFIGHTER’S SMOKE CONTROL STATION OPERATING INSTRUCTIONS For Use by Authorized Personnel Only LED INDICATORS: - ALARM has been received for the Zone - Equipment FAILURE AMBER - Controller communications FAULT or OVERRIDE - FAN is ON GREEN - DAMPER is OPEN - DAMPER is CLOSED YELLOW Press the LAMP TEST button to test all Indicators.
  • Page 158 Technical Manuals Online! - http://www.tech-man.com...
  • Page 159 ON, and the CLEAR FAULTS button must be pushed. The equipment that failed the self-test should be tested immediately to determine why it failed. Once the cause of the failure is determined, the equipment must be repaired. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 160 System Operation Controller Status Indicators Each of the Infinity controllers in the smoke control system has a number of status indicators. The following is a brief summary of some of the more commonly used indicators. For more information, refer to the controller’s installation guide.
  • Page 161 Each of the controllers in the TCX850 series and the TCX860 series has the following status indicators: CPU - Flashes every 0.2 seconds to show that the CPU is operating properly. Andover Controls Corporation 6-11 Technical Manuals Online! - http://www.tech-man.com...
  • Page 162 Power - Indicates that power has been applied to the unit. Port LEDs - Each Port has a RD LED and a TD LED to indicate the communications activity on that port. 6-12 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 163 Infinity CX Programmer’s Guide (P/N 30-3001-166) The Command Window The Command window is the top-level window in the Infinity system. From the Main Menu Bar, hit the F4 key to switch to the Command window. The cursor will now be at the R> prompt.
  • Page 164 This is very useful if you are debugging or testing a program and want to see how the program reacts to the points that are used in it. For example: R> Disable Zone4.PRS R> Enable Zone4.PRS 6-14 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 165 The system would then prompt you to hit any key when ready. At this point you should set up your computer to capture the data into a file, then hit any key. The Infinity system will then transmit all of the programs, files, and other information that is contained in all of the controllers in the system.
  • Page 166 When the system has completed transmitting the data, instruct your communications software to turn off the capture function and close the file. You now have a backup of your Infinity system. If there is ever a problem with your system, and you need to reload the programs, type in the following in the CX9200 Command window: R>...
  • Page 167 The View Pulldown Menu The VIEW pulldown menu on the Main Menu Bar allows you to look at various aspects of the Infinity system. Figure 6-5 shows the VIEW pulldown menu on the Main Menu Bar. Figure 6-5. The VIEW Pulldown Menu...
  • Page 168 • View Disabled Files - Prints out a list of all of the Files that are cur- rently disabled in the controller that you are connected to. 6-18 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 169 Appendix A Fire Panel Event Tables This appendix lists the Event tables for the Fire Panels. In the left column is the CX9200 Numeric Xdriver Point value, and in the right column is the Fire Panel Event that corresponds to that value. Refer to the Fire Panel manufacturer’s documentation for an explanation of the Events.
  • Page 170 Table A-2. EST Fire Panel Event Table CX9200 Numeric Model IRC-3 Fire Panel Event Xdriver Value NotSet None - Initial CX Value FIRE ALARM SECURITY ALARM SUPERVISORY SHORT SUPERVISORY OPEN SUPERVISORY FAULT EVENT SENSOR ALERT VERIFICATION Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 171 CX9200 Numeric Model IRC-3 Fire Panel Event Xdriver Value WATCHDOG FAULT FIRE ALARM RESTORED SECURITY RESTORED SUPERVISED SHORT RESTORED SUPERVISED OPEN RESTORED SUPERVISED FAULT RESTORED EVENT RESTORED SENSOR ALERT RESTORED UNKNOWN MESSAGE Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 172 Technical Manuals Online! - http://www.tech-man.com...
  • Page 173 Appendix B Points for System in This Manual This appendix lists all of the points that were used in the example system that is described in Chapter 5. There is a separate Table for each controller. These Tables do not include system variables. Technical Manuals Online! - http://www.tech-man.com...
  • Page 174 AH2EADmp.OVR.Opn Numeric AHU2 Exhaust Air Damper “OPEN” Override Switch on FSCS AH2OADmp.Cls Numeric AHU2 Outside Air Damper “CLOSED” LED on FSCS AH2OADmp.Fail Numeric AHU2 Outside Air Damper “FAIL” LED on FSCS Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 175 Numeric Floor2 Return Air Smoke Damper “CLOSED” LED on FSCS FL2RADmp.Fail Numeric Floor2 Return Air Smoke Damper “FAIL” LED on FSCS FL2RADmp.Opn Numeric Floor2 Return Air Smoke Damper “OPEN” LED on FSCS Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 176 FL3SADmp.OVR.Opn Numeric Floor3 Supply Air Smoke Damper “OPEN” Override Switch on FSCS FL3SADmp.ST.Fail Numeric Floor3 Supply Air Smoke Damper Self-Test Fail Flag FL3VAV.Cls Numeric Floor3 VAV Damper “CLOSED” LED on FSCS Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 177 Flag that tells the “Main” Program that the “FSCS_Interface” Program is Active Horn Numeric Audible Annunciator Output on FSCS LampTest Numeric “LAMP TEST” Pushbutton Input on FSCS Main.Key Numeric “MASTER KEY” Keyswitch Input on FSCS Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 178 Zone3 Smoke Control Sequence is Active Zone4.ALM Numeric Zone4 “ALARM” LED on FSCS Zone4.CON Numeric Zone4 Zoned Wiring Alarm Input on FSCS Zone4.EST Numeric Zone4 Xdriver Alarm Input from the Fire Panel Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 179 Input String that is Read from the FSCS that Indicates the Position of all the Switches LampWriteString String Output String that is Sent to the FSCS in order to set all of the LEDs Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 180 Output 6 Floor4 Return Air Smoke Damper Control Digital DefaultDmprPosn Numeric Damper Position when NOT Performing Smoke Control OverrideOn Numeric Flag that Indicates that an Output is Overridden at the Controller Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 181 Outside Air Damper Position when NOT Performing Smoke Control DefaultDmpr.RA Numeric Return Air Damper Position when NOT Performing Smoke Control OverrideOn Numeric Flag that Indicates that an Output is Overridden at the Controller Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 182 NAME TYPE DESCRIPTION SfanSt Input 1 Supply Fan Differential Pressure Proof Sensor Digital Sfan Output 1 Supply Fan Control Digital DefaultFanPosn Numeric Supply Fan State when NOT Performing Smoke Control B-10 Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 183 Appendix C FSCS Protocol This appendix describes the communications protocol for the FSCS. The FSCS uses a Q-Card processor board with the Andover Data Interface firmware. General Information The CX9200 communicates with the Q-Card via an RS-232 port. The Andover Data Interface firmware allows the CX9200 to control the state of the LEDs and read the state of the switches on the FSCS.
  • Page 184 The FSCS will transmit a ! character every time it receives a carriage return. This allows the CX9200 to supervise the RS-232 connection and verify that it is communicating properly with the FSCS. Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 185 In order to ensure that LEDs are updated after a power failure or after an interruption of the communications link, the LEDs should be refreshed frequently by the CX9200. Therefore, Andover Controls recommends using the block formatted command and updating all of the LEDs on a regular basis.
  • Page 186 Where nnn is the LED number ($nnn) The FSCS would respond with one of the three following messages: LED nnn is ON (Xnnn) (Znnn) LED nnn is OFF (Fnnn) LED nnn is FLASHING Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 187 When the switch actuation messages have been enabled, and the switch is polled, the switch states are not latched and the FSCS will report an instantaneous value for the switch. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com...
  • Page 188 (?nnn) Where nnn is the Switch number The FSCS would respond with one of the two following messages: (Annn) Switch nnn is Activated (ON) (Rnnn) Switch nnn is Released (OFF) Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
  • Page 189 Appendix D Manuals for the Smoke Control System This appendix gives a complete list of the manuals you may require to install and program your smoke control system. Technical Manuals Online! - http://www.tech-man.com...
  • Page 190 InfiLink 210 Installation Guide 30-3001-178 InfiLink 200 Installation Guide 30-3001-196 DCX 250 Installation Guide 30-3001-404 Infinity Modem Installation Guide and Command Reference 30-3001-166 Infinity CX Programmer’s Guide 30-3001-446 Infinity Smoke Control Guide Infinity Smoke Control Guide Technical Manuals Online! - http://www.tech-man.com...
