Installation and Layout
Table 3-2 shows the settings for the Options dipswitch..
Table 3-2. Q-Card Options Dipswitch Settings
Switch Position:
Auto-blanking ON
Auto-blanking OFF
9600 Baud
7200 Baud
4800 Baud
3600 Baud
2400 Baud
1200 Baud
600 Baud
300 Baud
Andover Controls recommends setting the FSCS for 9600 baud, with
auto-blanking disabled, therefore all the dipswitches are OFF.
Figure 3-6 shows the location of the switches on the Q-Card.
Figure 3-6. The Q-Card switch settings
Reset Switch
Andover Controls Corporation
Technical Manuals Online! - http://www.tech-man.com
1 2
ON
OFF
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Options Dipswitch
1 2 3 4
Q-CARD PROCESSOR PCB
3 4
OFF OFF
OFF ON
ON OFF
ON ON
OFF OFF
OFF ON
ON OFF
ON ON
3-11
