CX9200 Controller

The CX9200 serves as the central controller in the Infinity smoke
control system. It controls the communication between the other system
components within the smoke control system. The CX9200 can be used
in a dedicated or a non-dedicated smoke control application. The
CX9200 connects to other controllers in the following ways:
• The CX9200 connects to other CX9200 controllers via the EnergyNet
network.
• The CX9200 connects to the Infinet controllers, such as the SCX920S,
the TCX850 series, TCX 840 series, or the TCX860/865 series, via
the Infinet network.
• The CX9200 also connects to both the FSCS and Fire panel using 2
RS-232 ports.
When the CX9200 is utilized for smoke control, it performs the
following functions:
• Initializes the smoke control system.
• Receives fire alarms from the Fire Panel and instructs the Infinet
controllers to execute a smoke control strategy.
• Reads the manual override settings and updates the LEDs and alarm
on the FSCS.
• Performs weekly self-tests on all the dedicated components in the
smoke control system.
• Monitors the controllers in the smoke control system and signals the
FSCS when there is a communication fault or output override.
Features
• Plain English programming language
• 1 Energynet communications port
• 3 RS-232/RS-485 communications ports
• 1 RS-232/RS-485/RS-422 communications port
• Supports up to 254 Infinet controllers
• Battery backup: 1 hour full UPS to 72 hours for memory only
• 115V/230V AC power input
• DCX250 touch-screen display option
• 9600 bps Infinity Modem option
• ENL2500 Energynet repeater option
