SCX920S Controller

The SCX920S controller is used to control a large piece of equipment,
such an AHU (Air Handling Unit), or several smaller pieces of
equipment, such as smoke dampers. The SCX920S communicates with
the CX9200, as well as other Infinet controllers, via the Infinet network.
The SCX920S can be used in a dedicated or a non-dedicated smoke
control application.
Features
• Plain English programming language
• 16 Universal inputs that can be configured to measure Voltage,
Current, Temperature, or Digital (contact closure) values
• 8 Outputs that can be either FormC relay contacts, Voltage outputs,
or Current outputs
• 1 RS-485 Infinet port
• Lithium battery backup for memory and Real Time Clock
• 24V/115V/230V AC power input
• Available in either an open class plastic housing, designed to be
placed in a Listed enclosure, or as a fully enclosed unit with a locking
door
• Optional Local Display/Keypad option
