Listed 24V Step-Down Transformers - Andover Controls Infinity Manual

Installation and Layout
The TCX840 and TCX850 series
• Only an Andover Controls' Listed transformer may be used to supply the 24V AC
input power for the TCX840 and TCX850 series. These transformers must be placed
in a Listed enclosure and must be wired according to the National Electric Code, as
well as any state or local regulations.
Table 3-1 lists the step-down transformers that are available from Andover Controls.
• All of the Input and Output wiring on the TCX840 and TCX850 series must remain in
the same room.
The TCX860/865 series
• Only an Andover Controls' Listed transformer may be used to supply the 24V AC
input power for the TCX860/865 series. These transformers must be placed in a List-
ed enclosure and must be wired according to the National Electric Code, as well as
any state or local regulations.
Table 3-1 lists the step-down transformers that are available from Andover Controls.
Table 3-1. Listed 24V Step-down Transformers
Voltage PRI:SEC
115V : 24V
115V : 24V
277V : 24V
208/240V : 24V
• All of the Input and Output wiring on the TCX860/865 series must remain in the same
room.
The Infilink 200
• Any cables connected to the RS-232 port must be less than 20 feet in length, and must
be enclosed in conduit.
The Infilink 210
• The Infilink 210 must be used to electrically isolate the Infinet controllers that are
performing smoke control from the non-smoke control Infinet controllers. This is
Andover Controls Corporation
Technical Manuals Online! - http://www.tech-man.com
VA Rating Part Number
40 VA 01-2100-378
40 VA 01-2100-323
50 VA 01-2100-379
40 VA 01-2100-407
Primary and
Secondary
Connections
Solderless Lug
Wires
Solderless Lug
Wires
3-5
