Infinity Smoke Control System Components

Infilink 210

The InfiLink 210 is a fiber optic repeater for the Infinet network. The
InfiLink 210 is used to convert a single RS-485 Infinet signal into 2 fiber
optic Infinet channels. Therefore, if an Infilink 210 is used at each Infinet
controller, the entire network can use fiber optics. The Infilink 210 can
be used to electrically isolate one section of the Infinet network from
another section.
Features
• 1 RS-485 port
• 2 fiber optic ports. Each port has a Receive Data connection and a
Transmit Data connection.
• Switch selectable baud rates
• Enclosure is standard
• 115V/230V AC power input
Andover Controls Corporation 2-11
