Andover Controls Infinity Manual page 180

Table B-2. SCX920S
NAME
Fl2.SASDmp.Opn
Fl2.SASDmp.Cls
Fl2.RASDmp.Opn
Fl2.RASDmp.Cls
Fl3.SASDmp.Opn
Fl3.SASDmp.Cls
Fl3.RASDmp.Opn
Fl3.RASDmp.Cls
Fl4.SASDmp.Opn
Fl4.SASDmp.Cls
Fl4.RASDmp.Opn
Fl4.RASDmp.Cls
Fl2.SASDmp
Fl2.RASDmp
Fl3.SASDmp
Fl3.RASDmp
Fl4.SASDmp
Fl4.RASDmp
DefaultDmprPosn
OverrideOn
B-8
Technical Manuals Online! - http://www.tech-man.com
SMKDMPRS
Points
TYPE DESCRIPTION
Input 1 Floor2 Supply Air Smoke Damper OPEN Proof
Digital Sensor
Input 2 Floor2 Supply Air Smoke Damper CLOSED
Digital Proof Sensor
Input 3 Floor2 Return Air Smoke Damper OPEN Proof
Digital Sensor
Input 4 Floor2 Return Air Smoke Damper CLOSED
Digital Proof Sensor
Input 5 Floor3 Supply Air Smoke Damper OPEN Proof
Digital Sensor
Input 6 Floor3 Supply Air Smoke Damper CLOSED
Digital Proof Sensor
Input 7 Floor3 Return Air Smoke Damper OPEN Proof
Digital Sensor
Input 8 Floor3 Return Air Smoke Damper CLOSED
Digital Proof Sensor
Input 9 Floor4 Supply Air Smoke Damper OPEN Proof
Digital Sensor
Input 10 Floor4 Supply Air Smoke Damper CLOSED
Digital Proof Sensor
Input 11 Floor4 Return Air Smoke Damper OPEN Proof
Digital Sensor
Input 12 Floor4 Return Air Smoke Damper CLOSED
Digital Proof Sensor
Output 1 Floor2 Supply Air Smoke Damper Control
Digital
Output 2 Floor2 Return Air Smoke Damper Control
Digital
Output 3 Floor3 Supply Air Smoke Damper Control
Digital
Output 4 Floor3 Return Air Smoke Damper Control
Digital
Output 5 Floor4 Supply Air Smoke Damper Control
Digital
Output 6 Floor4 Return Air Smoke Damper Control
Digital
Numeric Damper Position when NOT Performing Smoke
Control
Numeric Flag that Indicates that an Output is Overridden
at the Controller
Example System Points
