- Page 1 SCX 920 Installation Guide Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
- Page 2 IMPORTANT NOTICE This product is subject to change without notice. This document does not con- stitute any warranty, express or implied. Andover Controls Corporation re- serves the right to alter capabilities, performance, and presentation of this product at any time.
- Page 3 Preface The SCX 920 Installation Guide presents instructions for installing the SCX 920 on an Infinet network. It first presents site preparation infor- mation and then step-by-step installation instructions. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
- Page 4 SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
-
Page 5: Table Of Contents
Contents Setting Up the SCX 920 Controller and Infinet Site/System Setup Requirements .............2 Controller Dimensions and Weight ..........3 Power Requirements ..............3 Cable Limitations ................3 Lightning Protection ..............4 Building Ground Requirements .............4 Inspecting the Ground ..............5 Environmental Requirements ............5 Output Equipment Requirements ..........6 Form C Outputs ................6... - Page 6 Wiring the Infinet to the SCX 920 ..........18 Wiring the Infinet to the Infinity CX 9000 ........19 Setting the Input Reference Resistor Switches ......19 Wiring the Inputs .................19 Wiring the Outputs ..............23 Wiring Tristate Outputs ...............23 Wiring Analog Outputs—Voltage ..........24 Wiring Analog Outputs—Current ..........25...
- Page 7 The Front Cover of the SCX 920 .........11 Figure 2. Locations of Screw Holes, Other Openings in Cabinet ..13 Figure 3. The Printed Circuit Board of the SCX 920 ......15 Figure 4. Metal Plate and Screw for Power Supply Wire ....17 Figure 5.
- Page 8 Wire Gauges and Corresponding Maximum Runs for Sensing Temperatures Up to 150º F .........9 Table 4. Connecting Jumpers for AC Input Voltages ......17 Table 5. Corresponding Override Switch Settings for Different Outputs Types ..........27 viii SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
-
Page 9: Setting Up The Scx 920 Controller And Infinet
Controller and Infinet This manual covers the following: • Site/System Setup Requirements • Installing the SCX 920 • Powering Up the SCX 920 Warranty Registration Your warranty is effective for 18 months starting on the date the system is shipped. -
Page 10: Site/System Setup Requirements
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada. SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com... -
Page 11: Controller Dimensions And Weight
Hardware Installation Controller Dimensions and Weight Each SCX 920 is 14.7 × 10.7 × 2.75 in. and weighs 8 lbs. Power Requirements Caution The SCX 920 should receive power from its own independent, unswitched circuit. You can select a power supply voltage of 24 V, 120 V, or 240 V. You receive it set to 115 V. -
Page 12: Lightning Protection
Two pair gas tube arrester, Andover Controls # 01-2100-299 Building Ground Requirements Warning Be sure that all Infinity products from Andover Controls Corporation are grounded to true earth ground. This kind of ground protects the equipment from transients and other power surges in the area. -
Page 13: Inspecting The Ground
Environmental Requirements The SCX 920 operates in rooms with temperatures ranging from 32 to 120°F and with humidity up to 85%, non-condensing. The controller must be in an Underwriter Laboratories approved enclosure. -
Page 14: Output Equipment Requirements
Hardware Installation Output Equipment Requirements The eight outputs on the SCX 920 are universal and can be wired to pro- vide direct digital control for virtually all electronic devices, pneumatic analog devices, and bi-directional motors and actuators. They can be wired so that you have Form C, analog (voltage or current), or tristate outputs, or a combination of them. -
Page 15: Input Circuit Specifications
Hardware Installation Input Circuit Specifications Caution Andover Controls inputs are designed to be used with two-wire devices and do not provide sufficient power to operate sensors or transducers requiring an external power supply. The following specifications apply to SCX 920 inputs: •... - Page 16 12,700 ft 6300 ft 2500 ft 7900 ft 3900 ft 1500 ft 5000 ft 2500 ft 1000 ft 3100 ft 1500 ft 600 ft 1900 ft 900 ft 300 ft SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
-
Page 17: Laying Out The Site Setup
• Communications port the Infinet connects to on Infinity CX 9000. Then collect the tags. You will need to know where your controllers are located when you later assign a name to each controller and each input and output. SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com... -
Page 18: Installing The Scx 920
• InfiLink 200s as Hubs, Repeaters, or Cable Switching Boxes Mounting Caution You must encase the SCX 920 in a UL approved cabinet to keep its Open Class rating. 1. Before you begin, look at the front of the SCX 920 cover. -
Page 19: Figure 1. The Front Cover Of The Scx 920
Hardware Installation Figure 1. The Front Cover of the SCX 920 SHIFT LOCK BACK SPACE CANCEL – ON 1/4 Turn Fastener ENTER +/– SCX 920 OVERRIDE EXTERNAL +24V 1/4 Turn Fastener SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com... -
Page 20: Disabling The Manual Overrides
Never drill holes in the SCX 920 cover or boards. A metal shaving could easily short circuit the electronics. 5. Screw the SCX 920 to the wall using standard No. 8 screws in the pre-cut holes in the four corners of the base plate. -
Page 21: Figure 2. Locations Of Screw Holes, Other Openings In Cabinet
1/8 A Auto INPUT - On REFERENCE RESISTOR OVERRIDE Auto + 24 V External Auto 1/8 A Form C Tristate – Auto INFINET RESET SHLD 1/8 A SERVICE EXPANSION PORT PORT SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com... - Page 22 You may want to refer to this figure for assistance in locating parts during the installation process. 1. Turn over the SCX 920 and remove the screw in the center of the board. 2. Turn the controller face up and lift out the snap latches around the edges of the plastic housing to remove it from the printed circuit board beneath it.
-
Page 23: Figure 3. The Printed Circuit Board Of The Scx 920
Hardware Installation Figure 3. The Printed Circuit Board of the SCX 920 Snap Latch Snap Latch LCD VIEW ANGLE INPUT EPROM USE COPPER CONDUCTORS ONLY AC INPUT VOLTAGE SELECTION 115V 230V From From From TP10 TP10 TP10 Snap F19, 3A, 250V... -
Page 24: Connecting The Battery
Figure 4 shows the position of the plate, where to place the wire, and how the screw fits on the plate. You can see how the screw holds the plate in place once you tighten it. SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com... -
Page 25: Selecting The Ac Input Voltage
To change the voltage from 115 V to 24 V, proceed as follows: 1. Disconnect the jumper end from E4 and move it to E3 so it jumpers E1 to E3. SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com... -
Page 26: Wiring The Infinet To The Scx 920
Class A FCC limits and to ensure reliable communications. Figure 5 illustrates how to wire the Infinet cable to the removable block terminal connector in the lower left corner of the SCX 920. Figure 5. Infinet Cable Wiring Infinet Connection... -
Page 27: Wiring The Infinet To The Infinity Cx 9000
See the Infinity CX 9000 Hardware Installation Guide for instructions. Setting the Input Reference Resistor Switches The inputs are on the lower left side of the SCX 920. To the right of the inputs are two DIP switches, with small switches for each input. Look closely at the switch and notice that each small switch is numbered. - Page 28 Never apply a voltage to a thermistor. Doing so alters the thermistor’s accuracy and reliability. You should replace a thermistor that has had voltage applied to it. Never bring a soldering iron to within 3 inches of the thermistor’s sensing tip. SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
-
Page 29: Figure 6. Wiring Diagram For Thermistor Input
Hardware Installation The inputs are on the lower left side of the SCX 920. Input wires should enter from that side. Notice that the inputs are labeled RET, 1, 2, RET, 3, 4, and so on. The first return terminal goes to the first two inputs, the second to the next two inputs, and so on. -
Page 30: Figure 8. Wiring Diagram For Voltage Input
(such as slightly over 20 mA), you should choose a value slightly below the maximum resistance you calculate. For example, you calculate the resistance for 0 to 20 mA: × ----- - 1000 500Ω m ax SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com... -
Page 31: Wiring The Outputs
Wiring the Outputs Wiring Tristate Outputs The outputs are down the entire right side of the SCX 920. All output wires should enter from the right. Notice that the first output is labeled from top to bottom NC, C, NO, I, V, GND. The next GND starts the second output, labeled GND, I, V, NC, C, NO. -
Page 32: Wiring Analog Outputs-Voltage
OUTPUT –ON Wiring Analog Outputs—Voltage The outputs are on the upper right side of the SCX 920. All output wires should enter from the right. You wire the outputs for voltage as follows: 1. Slip the appropriate wire under the V screw and tighten the screw down on it. -
Page 33: Wiring Analog Outputs-Current
Figure 11. Wiring Diagram for Voltage Outputs > or = 4KΩ – Wiring Analog Outputs—Current The outputs are on the upper right side of the SCX 920. All output wires should enter from the right. You wire the outputs for current as follows: Caution Remember that the current sources to ground. -
Page 34: Setting The Override Switches
AUTO so the controller can control it. Figure 14 shows a close-up of a single override rotary switch and how the settings change for voltage, current, or Form C. SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com... -
Page 35: Connecting Modules To The Expansion Port
Connecting Modules to the Expansion Port The expansion port at the bottom center of the controller board allows you to connect modules to expand the capabilities of the controller. Contact your Andover Controls representative for more information on expansion modules. SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com... -
Page 36: Powering Up The Scx 920
Hardware Installation Powering Up the SCX 920 Warning Before powering up the controller, be sure the board is jumpered for the correct input voltage. Before you proceed, be sure the following are correct: 1. Be sure you have jumpered the proper input voltage. -
Page 37: Reset Button
OVERRIDE light remains steadily on. 8. If the CPU light flashes every .1 sec, it means the CPU has failed a RAM or ROM test. See the Andover Controls Infinet Controller Troubleshooting Guide. 9. The EXTERNAL +24V light turns on and remains steadily on. -
Page 38: Completing The Installation
The SERVICE PORT on the far left side of the bottom of the controller is to connect the Andover Controls Service Tool to a SCX 920. The ser- vice tool will access all SCX 920s and other Infinet controllers on the same network. - Page 39 Infinet cable numbers 4 replacing 30 input reference resistor switch current outputs setting 19 wiring 25 inputs current sensors circuit specifications 7 resistor required 22 current wiring 22 resistor tolerance 23 SCX 920 Installation Guide Index-1 Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
- Page 40 24 power requirements voltage circuit 3 selecting for AC power 17 power surges voltage outputs preventing 4 wiring 24 powering up voltage sensors preparations for 28 wiring 22 Index-2 SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
- Page 41 5 counter inputs 21 current outputs 25 current sensors 22 Form C outputs 25 inputs 19 outputs 23 rules for inputs and outputs 20 thermistors 21 SCX 920 Installation Guide Index-3 Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
- Page 42 Index-4 SCX 920 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
- Page 43 30-3001-170 SCX 920 Installation Guide Rev D Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
