- Page 1 CMX 220 Installation Guide Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
- Page 2 IMPORTANT NOTICE This product is subject to change without notice. This document does not con- stitute any warranty, express or implied. Andover Controls Corporation re- serves the right to alter capabilities, performance, and presentation of this product at any time.
- Page 3 CMX controllers on an EnergyNet network. It first presents site preparation information and then step-by-step installation instructions. We recommend you read EnergyNet and Infinet Configuration Guide to plan your entire network before installing a single controller. Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
- Page 4 CMX 220 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
-
Page 5: Table Of Contents
Mounting and Wiring ..............10 Connecting the AC Power Cable to the Power Supply ..............12 Finding Ports for Connecting Other Cables .........13 Connecting the Terminal Screen ..........14 Connecting to the Built-in Modem ..........15 Andover Controls Corporation Technical Manuals Online! - http://www.tech-man.com firealarmresources.com... - Page 6 Connecting the Audio Speaker ............17 Powering Up the CMX ................18 Connecting the Battery ..............19 Interpreting Status Lights Inside Cabinet ..........20 Using the CLEAR MEMORY Button .........21 Connecting the Andover Controls Service Tool ......21 Appendix RS-232 Port Pinouts — CMX 220 Installation Guide Technical Manuals Online! - http://www.tech-man.com...
- Page 7 Dimensions and Eyelets for Mounting CMX Controller ..11 Figure 2. Metal Plate and Screw for Power Supply Wire ....12 Figure 3. Cable Ports and Connectors on the CMX 220 Controller ..15 Figure 4. Infinet Cable Wiring ............16 Figure 5. Audio Speaker Wiring ............17 Figure 6.
- Page 8 Tables Table 1. Number of Infinet Controllers Allowed on Various Models of CMX ..............6 viii CMX 220 Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
-
Page 9: Installing The Cmx Controller
Installing the CMX Controller The Infinity CMX (with or without a built-in modem) is a unique con- troller. You can connect a terminal to it and program it just as you would an Infinity CX controller, yet it belongs on the Infinet. You can connect four, 16, or 64 Infinet controllers to the CMX, depending on which par- ticular model number you have. -
Page 10: Site/System Setup Requirements
Site/System Setup Requirements Before you proceed to install the system, you should map out where you plan to install each controller, terminal/workstation, and modem. When planning the sites, be aware of any electrical interference that may oc- cur. You also need to be aware of cabinet dimensions, power requirements, cable limitations, and environmental requirements. - Page 11 Warning All wiring and installations must comply with local, state, and national electrical codes. Warning about Telephone Service Type of Service: The Infinity CMX controller is designed to be used on standard device telephone lines. It connects to the telephone line by means of a standard jack called the USOC RJ 11C (or USOC FJ45S).
-
Page 12: Cabinet Dimensions
FCC. In the event repairs are ever needed on the Infinity CMX controller, they should be performed by Andover Controls Corporation or an authorized representative of Andover Controls Corporation. For information contact Andover Controls at 300 Brickstone Square, Andover, Massachusetts 01810. -
Page 13: Built-In Modem
Built-in Modem The built-in modem, an optional feature of the CMX, has a 2400 baud rate. Audio Speaker Connector The speaker you may connect can have as much amplification as you want, but you must provide the power for it. Infinet Cables The maximum cable length for Infinet is 4,000 ft at 19,200 baud (up to 32 Infinet controllers). -
Page 14: Number Of Infinet Controllers On Cmx Infinet
You can have up to 64 Infinet controllers on a single CMX Infinet. shows the various model numbers and the number of Infinet controllers you can have on each.The differences between the CMX 220 and the Table 1. Number of Infinet Controllers Allowed on Various... -
Page 15: Building Ground Requirements
Building Ground Requirements Warning Be sure that all Infinity products from Andover Controls Corporation are grounded to true earth ground. This kind of ground protects the equipment from voltage transients and other power surges in the area. We cannot guarantee that the controller system will operate as documented unless you properly ground all controllers. -
Page 16: Inspecting The Ground
• Is connected to a corroded or galvanized pipe. • Is connected using a small gauge wire (less than 14 AWG). 2. Be sure your Andover Controls cabinet is connected to the ground with a copper conductor that terminates at the distribution panel. - Page 17 at any given time. The distant terminal automatically logs out the near- by terminal; so when planning your site, remember you can use only one terminal or the other at a given time and schedule time accordingly. You cannot connect an LBUS to a CMX controller. You cannot have an Infinity CX controller on the same Infinet with a CMX controller.
-
Page 18: Installing The Cmx Controller
Installing the CMX Controller Unpacking Be careful when unpacking the unit to not damage the packaging material—you must reuse it if you ship the product back for repair. Parts Required To install a single controller you start with the following parts: •... -
Page 19: Figure 1. Dimensions And Eyelets For Mounting Cmx Controller
Figure 1. Dimensions and Eyelets for Mounting CMX Controller 0.281 +.003 -.000 Hole Thru Install PEM Self-Clinching Standoff # BSO-8632-24-CI or Equivalent from Farside, 5 Places 2.000 ± .015 6.550 3.275 R .117 Full RAD 4 Places Places R .20 4 PLCS 11.50 10.400... -
Page 20: Connecting The Ac Power Cable To The Power Supply
Connecting the AC Power Cable to the Power Supply Warning Be sure the controller is not receiving AC power while you are wiring it, or you could receive an electrical shock that is life-threatening. 1. Open the cabinet door. Look to the upper left corner. You should see three screws labeled GND, RET, and 24V. -
Page 21: Finding Ports For Connecting Other Cables
5. Place the white wire under the metal plate behind the middle screw, labeled RET. 6. Tighten the screw with a flathead screw driver. 7. Place the black wire under the metal plate behind the bottom screw, labeled 24V. 8. Tighten the screw with a flathead screw driver. Finding Ports for Connecting Other Cables Figure 3 shows the inside of the CMX controller. -
Page 22: Connecting The Terminal Screen
Service Port The port labeled SERVICE PORT connects the Andover Controls Ser- vice Tool to the CMX controller. You can carry around the tool and plug it in as required to see how the controller system is functioning. See your Andover Controls representative about availability of the tool. -
Page 23: Connecting To The Built-In Modem
Figure 3. Cable Ports and Connectors on the CMX 220 Controller Connecting to the Built-in Modem If your CMX has a built-in modem, you connect a telephone line to the modem as follows: 1. Open your cabinet door and look for the MODEM label. The telephone jack is to the left of it. -
Page 24: Wiring Infinet To Cmx
2. Run telephone cable from the wall jack through the opening on the left side of the controller to the telephone jack (RJ 11 connector). Wiring Infinet to CMX You wire the beginning of Infinet to the Infinity CMX controller. After that you wire the Infinet to each Infinet controller. -
Page 25: Connecting The Audio Speaker
2. Take the first wire for the incoming Infinet and the first wire for the outgoing Infinet and slip both in the hole beneath the screw labeled with a plus sign (top). 3. Tighten the screw down on them until the screw holds the wires in place. -
Page 26: Powering Up The Cmx
Powering Up the CMX Before you proceed, be sure the following are correct: 1. Be sure the AC power is wired properly. Check to be sure all three wires have been connected. 2. Be sure the controller has a true earth ground. 3. -
Page 27: Connecting The Battery
6. If the CPU light flashes every 0.1 sec, it means the CPU has failed a RAM or ROM test. See the Andover Controls Infinet Controller Troubleshooting Guide. Connecting the Battery Once you have closed the AC power connection, you connect the bat- tery. -
Page 28: Interpreting Status Lights Inside Cabinet
Interpreting Status Lights Inside Cabinet Open the cabinet door and you see a string of green, yellow, and red lights, some of them flashing. Figure 6 shows how the lights appear. Figure 6. System Activity Status Lights (UserPort) RD (UserPort) TD (Modem Only) CXD INFINET TD SCAN... -
Page 29: Using The Clear Memory Button
The SERVICE PORT, on the far left side of the bottom of the control- ler, is to connect the Andover Controls Service Tool to an the CMX. The service tool will access all Infinet controllers on the same Infinet. For information on availability of the Andover Controls Service Tool, con- tact your Andover Controls representative. - Page 30 Infinity CMX Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
- Page 31 Appendix RS-232 Port Pinouts Table A-1 shows the pinouts for the RS-232 port on the Infinity CMX controller. If you choose, you may use a standard 25-pin ribbon cable for connect- ing a modem to either a controller or a terminal. However, to connect any terminal to a controller, you should use a cable with the required pinouts.
- Page 32 Table A-1. Pinouts for RS-232 Comm Port 1 with Male DB25 Connector to Terminal Pin Number Purpose Direction Required Chassis - - - From From - - - From –V From 1. “To” and “from” are in relation to the Infinity CMX controller. Infinity CMX Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
-
Page 33: Figure A-1. Pinouts For Cables Connecting To Rs-232 Ports
Figure A-1. Pinouts for Cables Connecting to RS-232 Ports on CMX Controller Female End Female End Connecting to VT 100 Connecting to or IBM PS/2 (25-pin) Infinity CMX Female End Female End Connecting to Connecting to IBM AT (9-pin) Infinity CMX Female End Female End Connecting to... - Page 34 Infinity CMX Installation Guide Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
- Page 35 Index ground AC power correcting 8 wiring 12 inspecting 8 Andover Controls Service Tool requirements 7 using 21 Infinet cabinet connecting 16 dimensions 4 lightning arrester for 6 cable Infinet cable for Infinet 5 connecting 16 for lightning protection 6...
- Page 36 requirements parts 10 RS-232 port pinouts A-1 SCAN light inside 21 service port location of 14 purpose of 21 shields for Infinet cable connecting 17 speaker amplification 5 TD light inside 20 temperatures for operating 8 terminal connecting 14 Underwriter Laboratories enclosure requirements 8, 10 wiring connecting Infinet cable 16...
- Page 37 30-3001-203 Infinity CMX 220 Installation Guide Rev D Technical Manuals Online! - http://www.tech-man.com firealarmresources.com...
