Example System Points
Table B-1.
NAME
AH2OADmp.Opn
AH2OADmp.OVR.Cls
AH2OADmp.OVR.Opn
AH2RADmp.Cls
AH2RADmp.Fail
AH2RADmp.Opn
AH2RADmp.OVR.Cls
AH2RADmp.OVR.Opn
AH2Rfan.Fail
AH2Rfan.On
AH2Rfan.OVR.Off
AH2Rfan.OVR.On
AH2Sfan.Fail
AH2Sfan.On
AH2Sfan.OVR.Off
AH2Sfan.OVR.On
AH3Sfan.Fail
AH3Sfan.On
AH3Sfan.OVR.Off
AH3Sfan.OVR.On
AH3Sfan.ST.Fail
AHU1.Fail
AHU1.OVRR
AHU2.Fail
AHU2.OVRR
AHU3.Fail
AHU3.OVRR
Fault.Clear
FIRST.SMK
FL2RADmp.Cls
FL2RADmp.Fail
FL2RADmp.Opn
Andover Controls Corporation
Technical Manuals Online! - http://www.tech-man.com
CX9200
Points
TYPE DESCRIPTION
Numeric AHU2 Outside Air Damper "OPEN" LED on FSCS
Numeric AHU2 Outside Air Damper "CLOSE" Override Switch on
FSCS
Numeric AHU2 Outside Air Damper "OPEN" Override Switch on
FSCS
Numeric AHU2 Return Air Damper "CLOSED" LED on FSCS
Numeric AHU2 Return Air Damper "FAIL" LED on FSCS
Numeric AHU2 Return Air Damper "OPEN" LED on FSCS
Numeric AHU2 Return Air Damper "CLOSE" Override Switch on
FSCS
Numeric AHU2 Return Air Damper "OPEN" Override Switch on
FSCS
Numeric AHU2 Return Fan "FAIL" LED on FSCS
Numeric AHU2 Return Fan "STATUS" LED on FSCS
Numeric AHU2 Return Fan "OFF" Override Switch on FSCS
Numeric AHU2 Return Fan "ON" Override Switch on FSCS
Numeric AHU2 Supply Fan "FAIL" LED on FSCS
Numeric AHU2 Supply Fan "STATUS" LED on FSCS
Numeric AHU2 Supply Fan "OFF" Override Switch on FSCS
Numeric AHU2 Supply Fan "ON" Override Switch on FSCS
Numeric AHU3 Supply Fan "FAIL" LED on FSCS
Numeric AHU3 Supply Fan "STATUS" LED on FSCS
Numeric AHU3 Supply Fan "OFF" Override Switch on FSCS
Numeric AHU3 Supply Fan "ON" Override Switch on FSCS
Numeric AHU3 Self-Test Fail Flag
Numeric AHU1 Controller "FAULT" LED on FSCS
Numeric AHU1 Controller "OVERRIDE" LED on FSCS
Numeric AHU2 Controller "FAULT" LED on FSCS
Numeric AHU2 Controller "OVERRIDE" LED on FSCS
Numeric AHU3 Controller "FAULT" LED on FSCS
Numeric AHU3 Controller "OVERRIDE" LED on FSCS
Numeric "CLEAR FAULTS" Pushbutton Input on FSCS
Numeric A Flag Indicating that the System has Already
Responded to the First Alarm
Numeric Floor2 Return Air Smoke Damper "CLOSED" LED on
FSCS
Numeric Floor2 Return Air Smoke Damper "FAIL" LED on FSCS
Numeric Floor2 Return Air Smoke Damper "OPEN" LED on
FSCS
