ImageXpress Pico Automated Cell Imaging System Installation Guide
1. If needed, do the following to disassemble the environmental control system:
a. Confirm that the valves on the tanks are completely shut off and that no gas is flowing.
b. On the environmental control tray, loosen the large screw to remove the cover from
c. Disconnect all tubing/wiring from the instrument and the humidifying column.
d. Remove the humidifying column from the environmental control tray.
e. Empty the humidifying column.
f. Pull the environmental control tray away from the instrument to remove it.
g. Pack the tubing/wiring inside the environmental control tray and replace the cover and
h. Pack the environmental control system components in their original packaging, as
80
the tray.
Note: See Connecting and Disconnecting Tubing on page 58
connecting tubing.
large screw.
shown.
for details on
