ImageXpress Pico Automated Cell Imaging System Installation Guide
Connecting and Disconnecting Tubing
As part of working with the environmental control system, you must connect and disconnect
tubing.
WARNING!
cylinder.
Connecting Tubing
To connect tubing:
1. Confirm that the pressure from the gas cylinder is turned off.
2. Push the tubing in to the port to connect it.
3. After inserting the tubing, gently pull the tubing to confirm it is seated.
Disconnecting Tubing
To disconnect tubing:
1. Confirm that the pressure from the gas cylinder is turned off.
2. Push in the outer ring as you pull the tubing.
58
Do not connect or disconnect tubing when there is pressure from the gas
5063666 K
