Appendix B: Optional Parts and Accessories

This section describes the items available from Molecular Devices for the ImageXpress Pico
system, including the following:
Objectives, see below
Filter Cubes, see below
Accessories, see page 72
See Obtaining Support on page 20

Objectives

The following Leica objectives, which are available from Molecular Devices, are compatible
with the ImageXpress Pico system:
Objective
PL FLUOTAR 4x/0.13
HC PL FLUOTAR 10x/0.32
HC PL FLUOTAR 20x/0.40
HC PL FLUOTAR L 40x/0.60 CORR
HC PL FLUOTAR L 63x/0.70 CORR
CAUTION! To prevent damaging both the instrument and your sample, do not use any
other objectives with the ImageXpress Pico system.

Filter Cubes

The following filter cubes, which are available from Molecular Devices, are compatible with the
ImageXpress Pico system:
Filter
DAPI
FITC
TRITC
Cy5
Texas Red
CFP
5063666 K
for details on contacting Molecular Devices.
Part Number
5064345
5064346
5064347
5064348
5064349
Part Number Excitation
5064350 370/40 nm
5064351 465/40 nm
5064352 530/45 nm
5064353 630/40 nm
5069939 560/50 nm
5069940 400/30 nm
Numerical
Mag. Aperture (NA)
4x 0.13
10x 0.32
20x 0.4
40x 0.6
63x 0.7
Emission
450/60 nm
525/30 nm
594/40 nm
695/45 nm
645/75 nm
480/40 nm
B
Working Corr.
Distance Collar
17.0 mm No
11.13 mm No
7.45 mm No
3.0 mm Yes
2.0 mm Yes
Dichroic
410 nm
500 nm
560 nm
655 nm
595 nm
475 nm
