ImageXpress Pico Automated Cell Imaging System Installation Guide
6. Do the following to connect the humidifying column:
a. Align the red dots to connect the electronics cable to the lower port on the
b. Connect the tubing with the blue band to blue port on the humidifying column.
c. Connect the tubing with the red band to red port on the humidifying column.
56
Note: See
Connecting and Disconnecting Tubing on page 58
connecting tubing.
humidifying column.
for details on
5063666 K
