ImageXpress Pico Automated Cell Imaging System Installation Guide

Using the Environmental Control System

This section provides details on setting up and using the environmental control system,
including the following:
Setting Up the Environmental Control System, see below
Connecting and Disconnecting Tubing, see page 58
Filling the Humidifying Column, see page 59
Loading the Environmental Control Cassette, see page 61
Using the Plate Skirt Height Adapter, see page 63
Setting Environmental Control Parameters, see page 64
Setting Up the Environmental Control System
To set up the environmental control system:
1. Confirm that the valves on the gas cylinders are completely shut off and that no gas is
flowing.
2. If the instrument is powered on, press the Power button on the front of the instrument to
turn off the power.
When the status light on the Power button is amber, the instrument is fully powered off.
54
Note: If the ImageXpress Pico system doesn't respond, you can perform a hard
shutdown by holding the Power button for five seconds.
