ImageXpress Pico Automated Cell Imaging System Installation Guide
Item
Reading Modes
Objectives
Fluorescence Color Channels
Environmental Control
Temperature Control
Ambient Operating Conditions
Ambient Storage Conditions
Altitude Restrictions
IEC Installation Category
Pollution Degree
Data Connection
IEC Ingress Protection
66
Description
Fluorescence
Transmitted Light (Brightfield)
Colorimetric
4x
10x
20x (optional)
40x (optional)
63x (optional)
FITC
DAPI (optional)
TRITC (optional)
CY5 (optional)
Texas Red (optional)
CFP (optional)
CO : 1% to 15% (optional)
2
O : 1% to 15% (optional)
2
Humidity: 85% (optional)
without environmental control cassette
6°C (11°F) above ambient up to 40°C (104°F)
with environmental control cassette
8°C (14°F) above ambient up to 40°C (104°F)
Temperature (general use without environmental control): 18°C
to 30°C (64°F to 86°F)
Temperature (when using temperature control): 18°C to 28°C
(64°F to 82°F); ambient temperature must be at least 8°C
(14°F) below the target temperature
Relative Humidity: 20% to 75% (non-condensing)
Temperature: -20°C to +60°C (-4°F to 140°F)
Relative Humidity: 15% to 75% (non-condensing)
Up to 2000 m (6,562 ft)
II
2
Two (2) Ethernet ports
IP20
5063666 K
