ImageXpress Pico Automated Cell Imaging System Installation Guide
To install a filter cube:
1. In the CellReporterXpress software, on the Home page, click
2. Click
install a filter cube.
3. Click the Filters tab.
4. In the tile for the filter cube slot where you want to install, click
5. Click the Choose Filter drop-down list box, and select the filter cube you want to install.
6. Click Open Maintenance Door.
7. If needed, slightly rotate the filter cube turret by hand to get direct access to the filter cube
slot.
8. Install the filter cube in the slot by gently pushing it into the slot until it "snaps" into place.
9. Do both of the following:
a. Manually close the maintenance door.
b. In the CellReporterXpress software, click Close Maintenance Door.
10. Click Apply.
44
Show Device Options to expand the details for the device where you want to
Note: Do not install a filter cube in slot 6 of the turret. Slot 6 must be empty (in both
the instrument and the software).
CAUTION! Retain the filter cube packaging. When not installed in the instrument, a
filter cube should always be stored in its original packaging.
Devices.
Component Exchange.
5063666 K
