Configuration Examples

OpenCom 100 in Computer Networks

One of the outstanding features of the OpenCom 100 is the integration of telephony
and computer networks. Connect the OpenCom 100 via a computer network (LAN)
with suitably configured workstations, and you can use its network features from
these workstations. Using a Web browser you can access:
• the OpenCom 100 Configurator
• call charge administration
• the OpenCTI 50, with which telephone functions can be used on a PC
• the OpenCom 100 central telephone book and your personal telephone book as
well as to the company telephone book (if the multi-company variant is activated).
In addition, the OpenCom 100 can be used as an Internet access server. RAS access
can also be implemented using the OpenCom 100, which enables the integration of
external staff in the LAN.
In this chapter you will find several examples of configurations showing integration of
the OpenCom 100 in a LAN. Which example applies to your situation depends on the
size and properties of the existing or planned LAN infrastructure.
Note
Several menu entries mentioned in this chapter are available only, if you switch on
the Level: Expert in the top level dialogue of the Configurator.
The following LAN prerequisites are possible:
Server configuration in the LAN
No IP server present
IP server present
DHCP server present
Configuration Examples
OpenCom 100 Functions
OpenCom 100 functions as DHCP and
DNS server
System Administrator must assign IP
address and DNS name for
OpenCom 100
93
