DECT over IP
IP-DECT
RFP 32: Access via shielded CAT5 Ethernet cable (STP cable, Shielded Twisted Pair
cable) with up to 100 metres of cable from the last Ethernet switch, integrated
antennas; 8 voice channels
RFP 34: like the RFP 32; mounted outside enclosed areas (IP55); external antennas
RFP 42: Access via shielded CAT5 Ethernet cable (STP cable, Shielded Twisted Pair
cable); offers simultaneous function of a WLAN Access Point conforming with the
IEEE 802.11b/g protocol; external antennas; 8 voice channels
When started, the operating software for the DECT over IP base stations is transmitted
via TFTP protocol from the OpenCom 100. The configuration for the start sequence is
transmitted by the DHCP server of the OpenCom 100 to a DECT over IP base station
for the start sequence.
IP-DECT (NG / New)
RFP 35: Access via shielded CAT5 Ethernet cable (STP cable, Shielded Twisted Pair
cable) with up to 100 metres of cable from the last Ethernet switch, integrated
antennas; 8 voice channels
RFP 36: like the RFP 35; mounted outside enclosed areas (IP55); internal antennas
RFP 37: like the RFP 35; mounted outside enclosed areas (IP55); external antennas
RFP 43: Access via shielded CAT5 Ethernet cable (STP cable, Shielded Twisted Pair
cable); offers simultaneous function of a WLAN Access Point conforming with the
IEEE 802.11a/b/g/n protocol; external antennas; 8 voice channels
The operating software for these DECT over IP base stations is transferred from the
OpenCom 100 at the first-time start with the TFTP protocol. For later starts, the oper-
ating software in the memory of the device is used. The configuration for the start
sequence is transmitted by the DHCP server of the OpenCom 100 to a DECT over IP
base station for the start sequence.
Note
You can simultaneously use older and newer DECT over IP base stations. In this case
you have to select a newer DECT over IP base station RFP 35/36/37/43 as
DECT over IP Manager.
142
