Installation

OpenCom 150

The listed interfaces and ports are located on the main module or on the connection
module of the OpenCom 150. Further interfaces and ports can be added by installing
additional interface cards (see Installing Interface Cards starting on page 35).
• One slot to incorporate a double doorstation equipment interface card. The fol-
lowing ports can be used with such a card:
Four actor ports for connection to a door opener and the intercom of doorstation
equipment. These are designed as pressure terminals (actor1 and actor3 to
activate door openers, actor2 and actor4 to activate doorstation equipment)
Four sensor ports for connection to the bell keys of doorstation equipment,
designed as pressure terminals (sensor 1 to sensor 4)
• One slot to incorporate a V.24 add-on card. The following port can be used with
the V.24 add-on card:
one COM port to connect to a PC to configure and transmit connection data,
designed as an RJ45 jack
• One PCM port for the connection of two systems, designed as an RJ45 socket
(PCM)
• Two ports to the LAN (100BaseT), designed as RJ45 jacks
• One CompactFlash socket to incorporate a type I or type II CompactFlash memory
card. The memory card is always necessary for operating the communications
system. The OpenCom 130 communications system is always delivered with a pre-
installed CompactFlash card.
• One jack to connect to the mains supply.
44
