Aastra 677x: Extensions and Accessories

Headset

A headset can be connected to the Aastra 6771 / 6773 / 6775 (OpenPhone 7x) system
telephones and to the Aastra 6773ip / 6775ip (OpenPhone 7x IP) IP system tele-
phones.
The headset must comply with the DHSG standard (connection via RJ45 jack). The
manufacturers Plantronics and GN Netcom make devices suitable for this purpose.
Alternatively, you can connect a "normal" headset (RJ11 jack) using an adapter. The
headset must comply with DIN Norm EN 60950-1 Point 6.2 ("Safety of information
technology equipment including electrical business equipment").
Connecting a Headset to a System Telephone
The connector for the headset is in the bottom of the system telephone's casing and is
indicated by this symbol
1. Plug the RJ45 jack on the headset cable into the socket provided.
2. Pass the cable through the recesses provided on the underside of the system tele-
phone.
3. Activate the headset on the system telephone in the menu Phone settings:
Headset (see also the system telephone's user guide).
