OpenCom 150
System data
Mains power supply
Rated power
Safety class
Permissible temperatures, stationary,
weatherproofed
Dimensions
Weight (system only)
S ports
0
Euro ISDN switchable (S
internal) for basic access, DSS1 proto-
col, or for ISDN terminals, DSS1 proto-
col
– Supply voltage
– Supply power
– Range
U ports
pn
for system terminals and RFP 22 / 24
DECT base stations
– Supply voltage
230 V ~ 50 Hz
160 VA
2
+5 °C to +40 °C
Wall version:
396 x 390 x 100 mm (W x H x D)
Rack version:
– Width: 19-inch panel with flange for
mounting in installation cabinet
– Height: 3 U
– Depth: approx. 340 mm
Wall version: 3.2 kg
Rack version: 7.8 kg
external / S Possible interface cards:
0 0
– 4 x S
– 2 x S
– 2 x S
40 V ± 10%
2 VA for internal
150 m internal
Possible interface cards:
– 4 x U
– 8 x U
– 2 x S
40 V ± 10%
Technical Specifications
0
and 6 x U
0 pn
and 6 x a/b
0
pn
pn
and 6 x U
0 pn
