2. Enter the network address of the VoIP system telephone. You have two connection
types to choose from under Connection to IP Phone:
– Deactivate the IP Phone address option to establish a broadcast connection via
"UDP-Broadcast". You have to select this type of connection if the VoIP system tel-
ephone has not yet been assigned an IP address. IP broadcasts cannot be trans-
mitted via router. The VoIP system telephone thus has to be directly connected to
your PC via a hub or via a switch.
– Activate the IP Phone address option to establish a point-to-point connection
via "UDP-Unicast". Enter the IP address of the VoIP system telephone into the entry
field. You can select this type of connection if the VoIP system telephone has
already been assigned an IP address.
3. Enter the MAC address of the VoIP system telephone. You will find the MAC
address on the underside of the device. Click on List configuration. The status bar
at the bottom edge of the programme window displays "list OK".
4. Change the desired settings under Configuration of the IP Phone. Click on Reset
configuration to activate the standard settings for all entry fields.
5. Click on the Send configuration command to transfer the currently shown con-
figuration to the VoIP system telephone. The status bar at the bottom edge of the
programme window displays "send OK".
Note
The VoIP system telephone receives the configuration and sends a response. The
new configuration is only saved and activated once this has happened. This can re-
sult in the "IP Phone Configurator" not receiving the response of the VoIP system tel-
ephone.
Please note:
You can implement the following settings:
If you are operating multiple network cards with active IP config-
uration in your PC, this may mean that the loading of configura-
tion data fails. First you deactivate additional network cards or
use a point-to-point connection. Sending configuration data
with a broadcast connection functions even without a response
from the VoIP system telephone.
