Software License Agreement Aastra Telecom Inc., hereinafter known as "Seller", grants to Customer a personal, worldwide, non-transferable, non-sublicenseable and non-exclu- sive, restricted use license to use Software in object form solely with the Equipment for which the Software was intended. This Product may inte- grate programs, licensed to Aastra by third party Suppliers, for distribution under the terms of this agreement.
Table of Contents Software License Agreement...iii About This Guide ...1 Introduction ...2 Requirements ...2 AastraLink RP 540 Gateway Parts...3 Setting Up Your System ...4 Wall-Mounted Unit ...4 Desktop Unit ...4 Connecting to Power and the Local Area Network...5 Connecting to Power ...5 Connecting to the Local Area Network ...5...
About This Guide This manual describes how to physically set up your new AastraLink RP 540 Gateway. This guide complements the AastraLink RP Administrator Guide and the AastraLink RP Quick Start Guide. AastraLink RP Administrator Guide – is designed for network system administrators who need information on installing and maintaining this product.
AastraLink RP solution is powered by Microsoft® Response Point™. Requirements The AastraLink RP 540 Gateway is part of the AastraLink RP solution, and is designed to work with the following components: •...
AastraLink RP 540 Gateway Parts When you unpack your AastraLink RP 540 Gateway you should have the following parts. If any part is missing, contact the supplier of your AastraLink RP 540 Gateway. • AastraLink RP 540 Gateway • Power adapter •...
Wall-Mounted Unit The template, screws, and anchors from the wall-mounting kit are used to mount the AastraLink RP 540 Gateway on the wall. The bottom of the unit should be against the wall when mounted. 1. Use the provided template to mark locations for mounting screws.
• Connect the Ethernet cable to the ethernet jack marked LAN on the AastraLink RP 540 Gateway, and connect the other end to your local area network (LAN). LAN Ethernet Switch , and plug the other end into an electrical outlet.
Connecting to the Local Phone Line The AastraLink RP 540 Gateway has 4 telephone jacks, allowing you to connect up to 4 local (FXO) phone lines. You must connect at least 1 phone line to the AastraLink RP 540 Gateway.
911, in addition to the caller’s telephone number. Compliance with such MLTS laws is your responsibility as the owner of Response Point. Response Point does not provide to emergency services the physical location/address of a phone that is used to call 911. AastraLink RP 540 Installation Guide...
This Class B digital apparatus complies with Canadian ICES-003. Cet appariel numérique de la classe B est conforme à la norme NMB-003 du Canada. Safety Certification This product is in compliance with regulations as follows: UL 60950-1 (1st Edition) AastraLink RP 540 Installation Guide...
Page 16
The information contained in this document is believed to be accurate and reliable at the time of printing. However, Aastra Telecom, Inc. cannot guarantee the accuracy of printed material after the date published nor can it accept responsibility for errors or omissions.
