1.
Specifications of Machine
I Product Code
CR-IR346RU
I Dimensions
W550 x D515 x H1065 (mm)
550
I Weight
155 kg approx.
I Means for Moving and Fixing the Machine
• Moving : Double-wheel caster (variable-direction/no-brake) x4
• Fixing
: • Adjustable foot x4
• Machine retainer x2
• Table x1 (optional)
• Table x1 and table retainer x2 (optional)
010-051-00
010-051-00
10.10.2000 FM2887 (2)
10.10.2000 FM2887 (1)
1065
515
Unit: mm
FR6H7645.EPS
CR-IR346RU Service Manual
IN - 2
