(8) Reverse the procedures for removing the flywheel.
N INSTRUCTIONS N
• The Kapton
arrow mark faces the side plate.
• After mounting the Kapton
Kapton belt does not come off.
(9) Reverse the procedures for removing the Kapton
(10) Reinstall the driven-shaft grip roller (upper).
"11.2 Subscanning Unit (Cleaning the Driven-Shaft Side Guide/Roller)
(11) Reinstall the cleaning brushes.
"11.1 Subscanning Unit (Cleaning the Cleaning Brushes)"
010-051-00 010-051-00
10.10.2000 FM2887 (2) 10.10.2000 FM2887 (1)
® belt should be mounted with its date indicating side up, so that the
® belt, manually rotate the flywheel to verify that the
®
Kapton belt
CR-IR346RU Service Manual
Side plate
Rotation mark
Date
FR6H6062.EPS
®
belt.
PM - 51
