3.9 High pressure pump

3.9 High pressure pump
3.9.1

Capillary connections high pressure pump/purge valve

28 ￭￭￭￭￭￭￭￭
The intelligent and low pulsation high pressure pump pumps the eluent
through the system. It is equipped with a chip on which its technical spec-
ifications and "life history" (operating hours, service data, ... ) are saved.
The purge valve is used for deaerating (see Chapter 3.9.2, page 30) the
high pressure pump.
Note
All of the capillary connections of the high pressure pump and the
purge valve are already installed in the newly delivered instrument.
1
2
3
4
5
6
2
7
Figure 13 Capillary connections high pressure pump/purge valve
2
13
2
8 9 2
10
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
12
2
11
2
882 Compact IC plus – Anion
