Metrohm 882 Compact IC plus Manual page 19

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
1 Knurled screws
For fastening the removable rear panel.
3 Mains connection socket
For connecting the mains cable.
5 USB connectors
2 USB connectors labeled with USB 1 and
USB 2.
7 Detector connection socket
For connecting Metrohm detectors. Labeled
with Detector.
9 Drainage tubing connector
For draining the escaped liquid from the
base tray through the connected drainage
tubing.
11 Drainage tubing connector
For supplying escaped liquid through the
connected drainage tubing to the leak sen-
sor.
13 Leak sensor connection socket
For connecting the leak sensor.
15 Service connection socket
For Metrohm service only.
17 Exhaust air opening
For extracting the air from the vacuum
chamber. Labeled with Exhaust.
19 Drainage tubing connector
For draining escaped liquid from the detec-
tor chamber through a connected drainage
tubing.
21 Drainage tubing connector
For draining escaped liquid from the flask
holder through a connected drainage tub-
ing.
882 Compact IC plus – Anion
2 Mains switch
For switching the instrument on and off.
I = On
O = Off
4 PC connection socket
For connecting the instrument to the com-
puter with the USB cable (6.2151.020).
6 MSB connectors
2 MSB connectors for connecting MSB devi-
ces. Labeled with MSB 1 and MSB 2.
MSB = Metrohm Serial Bus
8 Serial number
10 Leak sensor connection cable
Extractable. For connecting the leak sensor.
12 Device type
14 Transport locking screws
For securing the high pressure pump when
transporting the instrument.
16 Auxiliary connection socket
For connecting a 891 Professional Analog
out (2.891.0010).
18 Transport locking screws
Not Used.
20 Rear panel
Removable. Access to the detector chamber.
2 Overview of the instrument
￭￭￭￭￭￭￭￭ 9
