3.7 Capillary and cable feed-throughs

3.7 Capillary and cable feed-throughs
22 ￭￭￭￭￭￭￭￭
Installing drainage tubings
Proceed as follows to install the drainage tubings:
1 Connect drainage tubing (6-2) to the drainage tubing connection
(6-1) and shorten to the required length.
2 Connect drainage tubing (6-4) to the drainage tubing connection
(6-3) and shorten to the required length.
3 Connect drainage tubing (6-2) and drainage tubing (6-4) to the Y
connector (6-5).
4 Connect drainage tubing (6-6) to the Y connector (6-5), shorten to
the required length and connect the other end of the drainage tub-
ing to the drainage tubing connection (6-9).
5 Connect drainage tubing (6-7) to the drainage tubing connection
(6-8) and guide the other end into a waste container.
Several openings have been integrated for feeding through capillaries and
cables. These can be found at the door, at the rear panel, and below the
bottle holder and above the base tray (see Figure 7, page 23).
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
