Figure 9 Mounting Aspiration Filter; Figure 10 Install Tubing Weighting And Aspiration Filter - Metrohm 882 Compact IC plus Manual

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
1 Eluent aspiration tubing (6.1834.080)
3 O-ring
From accessories set (6.1602.160).
1 Filter holder
From accessories set (6.2744.210).
1 2
Figure 10 Install tubing weighting and aspiration filter
1 Eluent aspiration tubing (6.1834.080)
3 Tubing weighting
From accessories set (6.2744.210).
5 Aspiration filter (6.2821.090)
With filter holder from accessories set
(6.2744.210).
882 Compact IC plus – Anion
3 Mounting aspiration filter
Insert filter holder (9-1) into the aspiration filter (9-2) and screw
￭
tight.
1
Figure 9 Mounting aspiration filter
4 Install tubing weighting and aspiration filter
3
2 Tubing nipple
From accessories set (6.1602.160).
4 Bottle attachment
From accessories set (6.1602.160).
2
2 Aspiration filter (6.2821.090)
4
2 Eluent bottle attachment (6.1602.160)
4 Clamping screw
From accessories set (6.2744.210).
3 Installation
5
