3.3

Installation diagram

882 Compact IC plus – Anion
Rinse the instrument without column with eluent for 5 minutes.
￭
9 Installing guard and separation column
Remove the coupling (6.2744.040) between the column inlet
￭
capillary and the capillary of the MSM labeled with in.
Optional Connect guard column (see Chapter 3.16, page 46)
￭
– Fasten the guard column to the end of the column inlet
capillary (see leaflet to the guard column).
– Rinse the guard column with eluent for approx. 5 minutes.
Connect the separation column (see Chapter 3.17, page 47)
￭
– Connect the inlet oft the separation column either with the
end of the column input capillary using a short pressures
screw (6.2744.070).
OR
Connect the inlet of the separation column with the guard
column (if used) (see leaflets to the separation column and
the guard column)
– Connect the MSM capillary labeled with in with the output
of the separation column using a short pressure screw
(6.2744.070).
Hang separation column with chip in the column holder of the
￭
instrument.
10 Conditioning the instrument
(see Chapter 4.2, page 51)
The instrument is now ready for measuring samples.
The following installation diagram shows the schematics of the front of
the instrument after installation is complete. Many capillaries are already
installed at the time the instrument is delivered; these capillaries are not
numbered in the diagram. Numbered capillaries must be connected at the
time of installation.
