Please see the table below for the power module's packing list.
No.
1
2
3
4

5.8.1 Power Module Installation

stated in 5.4 Fixing the UPS, continue with the following steps to install the power module
(optional) into the UPS.
Modulon DPH Series
LED Indicator
Handle
Switch
(Figure 5-37: Power Module (Optional)
1
Item
Power Module
Bracket Ear
M6 Screw
M4 Screw
WARNING:
1. Only qualified service personnel can perform the following power module
installation procedures.
2. The power module is heavy (> 18 kg). At least two people are required for
handling.
3. Please follow your UPS capacity to install the correct number of power
modules. Please refer to the table below.
UPS
Capacity
Power Module
Q'ty
Fans
Handle
20kVA/ 40kVA/ 60kVA/
20kW 40kW 60kW
1 2
5-36
2 3
Q'ty
1 PC
2 PCS
4 PCS
8 PCS
80kVA/ 100kVA/
80kW 100kW
3 4 5
4
120kVA/
120kW
6
