Delta Modulon DPH Series User Manual page 154

UPS-1.1
Power Flow
3
After selection of 'YES', the UPS will shut down the inverter, terminate each power
module's output and transfer to run in Standby mode. At this moment, the tri-color LED
indicator illuminates yellow and the following screen (Figure 6-50) appears. For the tri-
color LED indicator location, please refer to Figure 2-12.
UPS-1.1
Power Flow
Power Flow
Summary
System Status
4
Switch OFF the Input Breaker (Q1), Bypass Breaker (Q2) and Output Breaker (Q4).
5
6
About 3 minutes later, the UPS will shut down, and the LCD and the tri-color LED
7
Switch OFF every external battery cabinet's breaker (Q5).
Modulon DPH Series
MEASUREMENT SETUP
Transfer to Bypass without Protection!
(Figure 6-49: Power off Reminder Screen)
MEASUREMENT SETUP
POWER FLOW
Maintenance
Bypass
Bypass
Mains
90 %
5 mins
EMS
(Figure 6-50: Standby Mode Screen)
MAINTENANCE LOG IN
User
POWER OFF ?
No
Yes
MAINTENANCE LOG IN
User
6-36
10:15
2
May 25,2018
WARNING
Battery
10:15
2
May 25,2018
WARNING
Standby
Load
0 %
