Using the C-Tong trigger button

49023, EN - rev. 4, 2020-01
When pressing the trigger button [1] on the C-Tong, the cylinder electrode
[2] moves out against the work piece and the welding cycle starts.
The welding cycle can be cut off before the welding current is activated
(approximately 0.5 sec) by releasing the trigger button.
When the welding current has started you can not cut off the welding cycle.
Always hold the C-Tong according to figure 4.4 below.
Figure 4.3 Using the C-Tong trigger button
Figure 4.4 Holding the C-Tong correctly during welding.
WARNING! The C-Tong must be held correctly during welding.
Risk of crushing (moving electrodes).
