Using The Ez-Kit Lite; Overview; Ez-Kit Lite License Restrictions; Memory Map - Analog Devices ADSP-21992 EZ-KIT LITE Manual

3 USING THE EZ-KIT LITE

3.1 Overview

This chapter provides specific information to assist you with developing your programs with the
ADSP-21992 EZ-KIT Lite board. This information appears in the following sections:
•

EZ-KIT Lite License Restrictions

•

Memory Map

•
Example Programs
•
Using the Flash Programmer Utility
This section provides programming information specific to the EZ-KIT Lite board. For more
detailed information about programming the ADSP-21992, see the documents referenced in
section 1.6.
3.2 EZ-KIT Lite License Restrictions
The license shipped with the ADSP-21992 EZ-KIT Lite imposes the following restrictions:
•
Program Memory (PM) space is limited to 8K words (1/4 of the ADSP-21992 PM space).
•
No connections to Simulator or Emulator sessions are allowed.
3.3 Memory Map
The ADSP-21992 has 48K words of internal SRAM that can be used for program storage or data
storage. The configuration of internal SRAM is detailed in the ADSP-2199x DSP Hardware
Reference.
ADSP-21992 EZ-KIT Lite Evaluation System Manual
Describes the restrictions of the EZ-KIT Lite demo license.
(Section 3.3)
Defines the memory map to assist in developing programs for the EZ-KIT Lite
evaluation system.
(Section 3.4)
Provides information about the example programs included in the ADSP-21992
EZ-KIT Lite evaluation system.
Provides information on the flash programmer utility included with
VisualDSP++.
(Section 3.2)
(Section 3.5)
3-25
