EZ-KIT Lite License Restrictions

EZ-KIT Lite License Restrictions
The license shipped with the EZ-KIT Lite imposes the following
restrictions.
• The size of a user program is limited to 8 KB of the ADSP-2189M
processor's internal memory space.
• No connections to Simulator or Emulator sessions are allowed.
• Only one EZ-KIT Lite board can be connected to the host PC and
debugged at a time.
• The EZ-KIT Lite hardware must be connected and powered up in
order to use VisualDSP++ with a kit license.

Memory Map

The ADSP-2189M EZ-KIT Lite board contains 80K bytes configured as
16K x 24 program memory and 16K x 16 of internal SRAM that can be
used for either program or data storage.
of the ADSP-2189M EZ-KIT Lite. The configuration of on-chip SRAM
is detailed in the ADSP-2189 Microcomputer Data Sheet.
Table 2-1. EZ-KIT Lite Memory Map
Start Address
PM 0x00000
PM 0x00030
PM 0x01800
PM 0x20000
DM 0x00000
2-2
End Address Content
Interrupt vector table
0x0002F
Available for user code
0x017FF
Reserved for monitor code
0x03FFF
Available for user code and up to four overlay pages
0x3FFF
Available for user data and up to six overlay pages
0x03AFF
ADSP-2189M EZ-KIT Lite Evaluation System Manual
Table 2-1 shows the memory map
