EZ-KIT Lite License Restrictions

EZ-KIT Lite License Restrictions
The license shipped with the EZ-KIT Lite imposes the following
restrictions.
• The size of a user program is limited to 8 KB of the ADSP-2181
processor's internal memory space.
• No connections to Simulator or Emulator sessions are allowed.
• Only one EZ-KIT Lite board can be connected to the host PC and
debugged at a time.
• The EZ-KIT Lite hardware must be connected and powered up in
order to use VisualDSP++ with a kit license.

Memory Map

The ADSP-2181 EZ-KIT Lite board contains 80K bytes configured as
16K x 24 program memory and 16K x 16 of internal SRAM that can be
used for either program or data storage.
of the ADSP-2181 EZ-KIT Lite. The configuration of on-chip SRAM is
detailed in the ADSP-2181 Microcomputer Data Sheet.
Table 2-1. EZ-KIT Lite Memory Map
Start Address
PM 0x0000
PM 0x0030
PM 0x17D0
PM 0x2000
DM 0x0000
2-2
End Address
0x002F
0x17CF
0x1FFF
0x3FFF
0x3AFF
ADSP-2181 EZ-KIT Lite Evaluation System Manual
Table 2-1 shows the memory map
Content
Interrupt vector table
Available for user code
Reserved for monitor code
Available for user code
Available for user data
