LLDP

5.1.4.5
The LLDP (Link Layer Discovery Protocol) function allows the switch to advertise its information to
other nodes on the network and store the information it discovers.
The following table describes the labels for the LLDP screen.
Label
LLDP Protocol
LLDP Interval
Apply
Neighbor Info Table
5.1.4.6 Backup & Restore
The current configuration from the switch can either be saved to the TFTP server, or restored from the
TFTP server on this page. The configuration file can also be saved to, and restored from a file on a local
PC.
iS5 Communications Inc.
Figure 19 - LLDP Configuration Interface
Description
"Enable" or "Disable" LLDP function.
The interval to resend LLDP (by default is 30 seconds).
Click "Apply" to activate the configurations.
Show LLDP Neighbors information.
Figure 20 - Backup & Restore interface
