Getting to Know Your Switch

1.1

About the iES6 Series Intelligent Managed Switch

The iES6 series switches are powerful, managed industrial grade switches with numerous features.
These switches can operate under a wide temperature range, dusty environments, and in humid
conditions. The switches can be managed either by using the WEB, TELNET, directly using the
Console port on the switch, or any third-party SNMP software. The switch can also be managed by
our own Network Management Suite called "iManage". iManage has a friendly and powerful
interface which can be easily used to configure multiple switches at the same time, and also monitor
their status.
1.2

Software Features

World's fastest Redundant Ethernet Ring (Recovery time < 30ms with up to 250 units)
Supports Ring Linking, Dual Homing over iRing, and standard RSTP
Supports SNMPv1/v2c/v3 & Port base VLAN Network Management
Event notification by Email, SNMP trap and Relay Output
Web-based ,Telnet, Console, CLI configuration
Port Based VLAN to segregate and secure network traffic
SNMPv3 encrypted authentication and access security
RSTP (802.1w)
Port configuration, status presentation
Windows utility (iManage) for network management
1.3

Hardware Features

4 x 10/100Base-T(X) Ethernet ports
2x 100Base-X SC or ST Fiber ports
Console Port
Dual Input low-voltage (LV) DC (10-48VDC)
Dual Input medium-voltage (MV) DC (36-75VDC)
Single Input Hi-voltage (HV) AC/DC input (85-264VAC, 88-300VDC) with Single (10-48VDC) backup
Wide Operating Temperature: -40 to 85
Storage Temperature: -40 to 85
Operating Humidity: 5% to 95%, non-condensing
Chassis: IP-40 Galvanized Steel
Dimensions – iES6 (W x D x H) : 101.8(W) x 128.8(D) x 176.7(H) mm (4.01x5.07x6.92 inch.)
Dimensions – iES6-S (W x D x H) : 65.13(W) x 160.49(D) x 191.267(H) mm (2.56x6.32 x7.53inch.)
iS5 Communications Inc.
o
C
o
C
iES6 Series User's Manual
8
