IP Setting

5.1.4.3
The IP Settings and DHCP client function can be configured through IP configuration.
The following table describes the labels for the IP Configuration Interface screen.
Label
DHCP Client
IP Address
Subnet Mask
Gateway
DNS1
DNS2
Apply
iS5 Communications Inc.
Figure 17 - IP Configuration Interface
Description
Enables or disables the DHCP client function. When the DHCP client function
is enabled, an IP address from the network DHCP server will be assigned to
the switch. The default IP address will be replaced by the IP address which
the DHCP server. After clicking "Apply", a popup dialog shows up to inform
you that the DHCP client is enabled. The current IP will be lost and you
should see the new IP address on the DHCP server.
Assigns the IP address that the network is using. If the DHCP client function
is enabled, you do not need to assign an IP address. The network DHCP
server will assign the IP address for the switch and it will be displayed in this
column. The default IP is 192.168.10.1.
Assigns the subnet mask of the IP address. If the DHCP client function is
enabled, you do not need to assign a subnet mask.
Assigns the network gateway for the switch. The default gateway is
192.168.10.254.
Assigns a primary DNS IP address.
Assigns the secondary DNS IP address.
Click "Apply" to activate the configurations.
