Terminal
Description
Number
7 PWR2 (-) : Negative
8 RLY NO
9 RLY CM
10 N/C
2. MV: Dual Input 36-75VDC
Terminal
Description
Number
1 PWR1 (+): Positive
2
PWR1
3 PWR1 (-) : Negative
4
: Chassis Ground
5 PWR2 (+) : Positive
6
PWR2
7 PWR2 (-) : Negative
8 RLY NO
9 RLY CM
10 N/C
3. HV: Single Input 85-264VAC or 88-370VDC with a Single 10-48VDC Backup
Terminal
Description
Number
1 PWR1 (+/L) – Line or Positive
2
PWR1
iS5 Communications Inc.
Connection
Connected to the negative terminal of the 2
power source.
Failsafe relay, normally open contact.
Failsafe relay, common contact.
No connection
Connection
Connected to the positive of the 1
source.
Power supply 1 ground connection.
: Ground
Connected to the negative of the 1
source.
Connected to the safety ground terminal for AC Units or
the ground bus for DC inputs. Chassis ground connects to
both power supply surge grounds via a removable jumper.
Connected to the positive terminal of the 2
power source.
Power supply 2 ground connection.
: Ground
Connected to the negative terminal of the 2
power source.
Failsafe relay, normally open contact.
Failsafe relay, common contact.
No connection
Connection
Connected to the line terminal of the 85-264VAC power
source or the positive terminal of the 88-370VDC power
source.
Power supply 1 ground connection.
– Ground
