Panic

CEM3 offers a panic capability that complies with the UL 924 standard.
When a properly connected and enabled CEM3 has a panic "look" stored, it will automatically play the
recorded look when it receives a signal over the panic circuit.
Panic can be enabled when a maintained (normally open or normally closed) contact closure is properly
wired to the backplane. For more information, see the data termination guide or installation guide that
was supplied with the rack.
For information on how to configure panic on your CEM3, see
Note:

Patch

Patching governs the relationship between control input sources (DMX A, DMX B, and sACN) and the
control of circuits in the rack. This relationship can be edited to match the needs of your control
sources and rack constraints. For information on patching, see
8
To configure panic mode through an electrical override without using the CEM3
module software, order the Hardwired Panic Accessory (7140K1002). Contact your
local dealer for more information.
Setting Up Panic page 32
on
Patching page 34
on .
.
