Dimmer Curves

Dimmer curves determine voltage output in response to control signal input. To accommodate
designer preferences and load response variations, Sensor3 offers several dimmer curves, which can be
applied to individual dimmers (see
The available curves in CEM3 are as follows.

Linear

The linear curve matches the control input percentage to Root Mean Squared (RMS) voltage output.
Each percent increase in control level increases dimmer voltage output by the same amount.
100
80
60
40
20
0

Modified Linear (Mod-Linear)

A modified linear curve reduces the voltage change at low control levels for better performance in
low-wattage fixtures.
100
80
60
40
20
0
System Reference
Curve
0 20
Control Input (%)
0 20
Control Input (%)
page 18
on ).
40 60
40 60
80 100
80 100
