Test
Field
Set Local Levels
Set System Levels
Dimmer Check
Release Systm Lvls
Presets
Sequences
Release All Arch
Record Rig Check
Run Rig Check
Clear Rig Check
12
Set levels for outputs from this rack only. This will present a table-style view
of the outputs in this rack and allow setting and releasing of levels. To set
levels:
•
Select a circuit by numeric entry or scrolling with the wheel
•
To select a range of circuits, use [thru] and [and].
- Press [Last/A] or [Next/B] on the keypad to set a level for the A or B
side of dimmer doubled circuits. See example below.
•
Press [at].
•
Use numeric entry or scroll to select a level. 0–100 is the valid range.
100 will display as "FL".
•
Press [Enter]. The selected circuits will be set to the specified level or
released if you did not enter a level.
Set levels for chosen circuits in a space. See
necessary, double press [Back] to clear the command line during any of the
following steps.
1: Use the keypad to enter a circuit number between 1 and 99999.
2: Press [and] to enter multiple circuits or press [thru] to enter a range of
circuits.
• Press [Last/A] or [Next/B] on the keypad to set a level for the A or B
side of dimmer doubled circuits. See example below.
3: Press [at] or [Enter]. The command line ends with "at".
4: Use the keypad or scroll wheel to enter a level if desired. 0–100 is the
valid range. 100 will display as "FL".
5: Press [Enter]. The selected circuits will be set to the specified level or
released if you did not enter a level. The command line ends with "*".
6: If you selected a single circuit, press [Next] or [Last] on the keypad to
increment or decrement the circuit number to set the level of another
circuit, if desired.
Quickly run through all lugs or all circuits in a space to test their output at a
given percentage.
Release any active levels for a given space at once.
Record or play back presets. See
Record or play back sequences. See
page 29
.
Release all architectural control such as presets, sequences, and set zone
levels.
Record a rig check preset to facilitate AF reporting. Rig Check features are
only available if the rack property AF Enabled is set to Yes. See
page 10
Advanced Features (AF)
on
,
Definitions
page 20
on
Run a rig check preset. You will be notified of any load inconsistencies
found during the rig check.
Clear the recorded rig check from all racks for a given space.
Description
Example
Recording and Playing Presets
Recording and Playing Sequences
page 6
on
for more information.
on the next page. If
page 27
on
Rig Check
Rack Property
, and
CEM3 User Manual
.
on
