Rack Property Definitions
Each rack has specific properties that dictate how the rack is identified and functions. Edit these
properties in the Rack Setup screen ([Setup]>Rack).
Rack Property
Rack Number
System Number
DMX A
Priority (DMX A)
DMX B
Priority (DMX B)
sACN
Arch Priority
Off as Release
Fan
AF Enabled
Presets on Boot
Setup at Home
Volt High Warn
Temp High Warn
Station Power
Remote Record
[Data Loss Behavior]
20
Select a rack number between 1–999.
Select a system number between 1–999. Default is 1. Changing the
system number will require a reboot.
Enable or disable the DMX A port. When Disabled the respective Priority
field is not visible, and Off is displayed on the home screen. Default for
DMX A is Enabled.
Visible only when DMX A output is Enabled. Configure the priority of the
DMX A output signal from the rack. Range is between 1–200
(200 = highest priority). Default is 100.
Enable or disable the DMX B port. When Disabled the respective Priority
field is not visible, and Off is displayed on the home screen. Default for
DMX B is Disabled.
Visible only when DMX B output is Enabled. Configure the priority of the
DMX B output signal from the rack. Range is between 1–200
(200 = highest priority). Default is 100.
Enable or disable the sACN port. When Disabled, Off displays on the
home screen. Default for sACN is Enabled.
Set the priority used for preset playback. Range is between 1–200
(200 = highest priority). Default is 100.
Select Yes to revert from architectural preset control to DMX or sACN
console control when the Off preset is activated. Select No to maintain
preset control and play the Off preset until you select Release All Arch.
The length of time (in minutes) the rack fan will stay on after the last load
in the rack has reached 0%. Select a time between 30–180 minutes or
Always-On. Default is 30.
Set whether Advanced Features (AF) are enabled (Yes/No). Default is
based on the backplane DIP switch setting.
If Enabled and the rack is rebooted when a preset (or presets) are active,
those same presets will be reactivated when the rack reboots.
Set whether Quick Setup is displayed on the home screen. Default is Yes
for portable racks and No for install racks.
Set the threshold voltage to report an "over voltage" condition
140VAC for 100–120VAC systems and 250VAC for 230–240VAC
systems.
Set the threshold temperature to report an "over temperature"
condition. The range is between 32–158°F (0–70C). Default is 149°F
(65C).
Set whether the preset station power supply for this CEM3 is turned on.
Preset Functions
Default is Off (see
Set whether presets can be remotely recorded from preset stations.
Default is No.
Opens the Data Loss Behavior submenu (see
page 35
on
).
Definition
page 9
on
for more information).
Setting Data Loss Behavior
Default is
.
CEM3 User Manual
