Home Screen; Normal Operation; Panic; Af Card Upgrade - ETC Sensor3 CEM3 User Manual

Home Screen

Normal Operation

Rack #1 - CEM3 Rack Rack #1 - CEM3 Rack
System OK System OK
Presets Active
10.101.101.101
DMX A: Off DMX A: Off
sACN: 1/1 sACN: 1/1
[Quick Setup]
[Quick Setup]

Panic

Rack #1 - CEM3 Rack Rack #1 - CEM3 Rack
System OK System OK
Presets Active
10.101.101.101
DMX A: Off DMX A: Off DMX B: Off DMX B: Off
sACN: 1/1 sACN: 1/1
Panic Active!
[Quick Setup] [Quick Setup]

AF Card Upgrade

Rack #1 - CEM3 Rack Rack #1 - CEM3 Rack
System OK Upgrading AF Card #1
Presets Active
10.101.101.101
DMX A: Off DMX A: Off DMX B: Off DMX B: Off
sACN: 1/1 sACN: 1/1
[Quick Setup] [Quick Setup]

Battery Backup or RideThru Active

Rack #1 - CEM3 Rack Rack #1 - CEM3 Rack
System OK System OK
Presets Active
10.101.101.101
DMX A: Off DMX A: Off DMX B: Off DMX B: Off
sACN: 1/1 sACN: 1/1
Backup Power ACTIVE!
[Quick Setup] [Quick Setup]

Redundant Tracking

Processor A in Control
Rack #1 - CEM3 Rack Rack #1 - CEM3 Rack
System OK
System OK
Presets Active
10.101.101.101
DMX A: Off DMX A: Off DMX B: Off DMX B: Off
sACN: 1/1 sACN: 1/1
[Quick Setup] [Quick Setup]
Rack #1 - CEM3 Rack CEM3 Control
System OK
Backup Ready
DMX A: Off DMX B: Off
sACN: 1/1
[Quick Setup]
CEM3 Menu Flow Chart
Notes:
DMX B: Off DMX B: Off
[Info]
[Info]
Panic is active.
Note:
See Setup menu flow chart
for Panic settings.
[Info] [Info]
AF Card is being upgraded.
Note:
[Info] [Info]
Backup battery or RideThru
Note:
is active.
[Info] [Info]
Redundant Tracking:
the home screen of
Note:
processor A when
processor A is in control.
[Info] [Info]
Redundant Tracking:
the home screen of
Note:
processor B when
processor A is in control.
[Info]
displays rack number and rack name
displays "System OK" if no error state exits. If error states exits, the system status display will scroll through errors.
Highlight an error and press [Enter] to clear it.
displays the first DMX A and DMX B patched values by lug or "OFF"
displays the current sACN address in universe/channel or absolute format depending on configuration setting
(see UI Preferences) or "OFF"
[Quick Setup] is shown if the rack property "Setup at Home" is set to Yes. See Rack in the Setup menu flow chart.
Highlight [Quick Setup] and press [Enter] to access the Quick Setup menu (see the Quick Setup menu flow chart).
Highlight [Info] and press [Enter] to access View/Clear Errors (see the Info menu flow chart below the
Quick Setup menu flow chart).
Rack #1 - CEM3 Rack Rack #1 - CEM3 Rack
System OK System OK
Presets Active
10.101.101.101
DMX A: Off DMX A: Off DMX B: Off DMX B: Off
sACN: 1/1 sACN: 1/1
Panic Ended!
[Quick Setup] [Restore Control] [Info]
Processor B in Control
Rack #1 - CEM3 Rack CEM3 Control
System OK
Backup Active
DMX A: Off DMX B: Off
sACN: 1/1
[Quick Setup] [Info]
Rack #1 - CEM3 Rack Rack #1 - CEM3 Rack
System OK System OK
Presets Active
10.101.101.101
DMX A: Off DMX A: Off DMX B: Off DMX B: Off
sACN: 1/1 sACN: 1/1
[Quick Setup] [Quick Setup] [Info] [Info]
Panic operation:
If Out Delay is set to Manual,
following clearing of the
electrical panic select
Note:
[Restore Control] to clear
the panic look.
Redundant Tracking:
the home screen of
Note:
processor A when
processor B is in control.
Redundant Tracking:
the home screen of
Note:
processor B when
processor B is in control.
